Viewing Options Within a Menu

The options can be viewed inside a particular menu by pressing
the S push button when the Menu Message appears on the dis-
play. For example, to look at the options in the Door Operation
Menu, first press the N push button until the Door Operation Menu Message appears:
Press the S push button. The following display will appear:
To view the next option, press the N push button. Hold down the
N push button to scroll through the options. Eventually the Menu Message will reappear, or to
return directly to the Menu Message while the options are displayed, press the N and '+' push
buttons at the same time. Press the S push button to see the options for that same menu again,
or press the N push button to go on to the next menu.

Changing a Value

For each option that appears, the value can be changed by pressing the S push button. While in
the Timer, Spare Inputs and Spare Outputs menus, pressing and holding the S push button for
five seconds causes the display to scroll through the values at a faster rate. Also, in those same
menus, pressing the S and '-' push buttons at the same time will cause the display to scroll back-
wards and pressing the S and '+' push buttons at the same will reset the option to NOT USED.
To return directly to the Menu Message while the values or options are displayed, press the N
and '+' push buttons at the same time.
Going back to the previous example in which the Nudging option
was on the display:
Pressing the S push button to changes Nudging to NO:

Saving the New Values

Whenever options or values are changed in Program mode, this
information must be saved in the computer's memory. When the
changes are complete, press the N push button until the follow-
ing message appears:
Press the S push button to save the changes. The Start Message will appear again. When pro-
gramming is complete, move the F1 switch back to the down position.
Note
If the values have not been saved, they will be lost when F1 is switched back to OFF (down) posi-
tion. Make sure to keep an account of saved changes on the record provided in Appendix A.

Restoring Original Values

When using Program mode, if some values have been changed, but then you decide to go back
to the old values, exit Program mode without saving the changes. Move the F1 switch back to
the down position and the original values will be restored.
F1: Program Mode
*DOOR OPERATION*
MENU
NUDGING? YES
NUDGING? YES
NUDGING? NO
*SAVE CHANGES?*
* N=NO S=YES *
5
5-15
