Motion Control Engineering 2000 Manual page 175

Table 5.15 Controller Board CTL B Processor Diagnostics
Address
16 = (n/a)
15 = (n/a)
14 = (n/a)
13 = (n/a)
12 = (n/a)
11 = (n/a)
10 = Up slowdown
09 = Down slowdown
302
08 = Near top
07 = Near bottom
06 = Up direction limit
05 = Down direction limit
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
16 = UETS status
15 = UTS1 status
14 = UNTS2 status
13 = UNTS3 status
12 = UNTS4 status
11 = UNTS5 status
10 = DETS status
09 = DNTS1 status
303
08 = DNTS2 status
07 = DNTS3 status
06 = DNTS4 status
05 = DNTS5 status
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
400 Down distance @ 100% of contract speed
401 Down distance @ 90% of contract speed
402 Down distance @ 80% of contract speed
403 Down distance @ 70% of contract speed
404 Down distance @ 60% of contract speed
405 Down distance @ 50% of contract speed
406 Down distance @ 40% of contract speed
407 Down distance @ 30% of contract speed
408 Down distance @ 20% of contract speed
409 Down distance @ 10% of contract speed
410 Up distance @ 100% of contract speed
411 Up distance @ 90% of contract speed
412 Up distance @ 80% of contract speed
413 Up distance @ 70% of contract speed
414 Up distance @ 60% of contract speed
415 Up distance @ 50% of contract speed
416 Up distance @ 40% of contract speed
F5: Controller Utilities/Monitoring and Reporting
Item Notes
5-95
5
