Table 6.3 HC-CTL-2 Board Terminals
Connector Terminal
J15 1
MCE wired
DCOM
at factory.
2
Not for field
2MV
connection.
2L
J16 DZR
MCE wired
DZF
at factory.
DLAT
Not for field
DLMS
connection.
DLABR
DCABR
GSR
J17 SPIN1
SPIN2
SPIN3
SPIN4
SPIN5
SPIN6
SPIN7
SPIN8
SPIN9
SPIN10
Ground
Digital Common
120 VAC
Provides 120VAC to 2L bus when SAFL and SAFS relays are picked (input).
Provides 120VAC to valves and motor signals when doors are locked and safety
string is made up (Output).
See description, connector J12
See description, connector J12
See description, connector J12
See description, connector J12
See description, connector J12
See description, connector J12
See description, connector J12
Programmable spare input #1. Defined on job prints if used.
Programmable spare input #2. Defined on job prints if used.
Programmable spare input #3. Defined on job prints if used.
Programmable spare input #4. Defined on job prints if used.
Programmable spare input #5. Defined on job prints if used.
Programmable spare input #6. Defined on job prints if used.
Programmable spare input #7. Defined on job prints if used.
Programmable spare input #8. Defined on job prints if used.
Programmable spare input #9. Defined on job prints if used.
Programmable spare input #10. Defined on job prints if used.
