SPEED > 150 FPM?
code compliant hydraulic elevators with speeds exceeding 150 FPM. When on Inspection opera-
tion, running at high speed is prevented by disabling the FUD output.
DOOR POSITION MONITOR:
cates the use of a door position monitor on front, rear or both doors (DPM / DPMR inputs) in
order to enable the door position monitor logic.
FRONT DOOR CLOSE LIMIT?
limit signals used by this car. (DCL for door close limit switch. GS and DCAB for gate switch and
door closed bottom access. None.)
REAR DOOR CLOSE LIMIT?
limit signals used by this car. (DCL for door close limit switch. GS and DCAB for gate switch and
door closed bottom access. None.)
LS-EDGE LANDING SYSTEM?
landing system.

Timed Features

This menu allows you to select and program features that will be executed based on a time
schedule.
SYNC. OP. DAYS
+ push buttons to select (YES/NO) the day(s) on which the Synchronization operation is to be
performed (use in lieu of SYNCI input,
SYNC. STARTING TIME
time at which the Synchronization operation is to begin
TIMER" on page
(YES/NO) - This option must be set to YES on ASME A17.1-2000
(NONE/FRONT/REAR/BOTH) - This parameter indi-
(NONE/DCL/GS+DCAB) - Set to the front door close
(NONE/DCL/GS+DCAB) - Set to the rear door close
(YES/NO - Set to YES if you are using the LS-EDGE
(EVERYDAY, MON, TUE, WED, THUR, FRI, SAT, SUN) - Use S and
see "SYNCI" on page
(24 hour format / 30 minute increments) - Set the
5-28).
F1: Program Mode
5-38).
(see "SYNC. OP. DELAY
