Motion Control Engineering 2000 Manual page 160

The Computer
Table 5.14 Controller Board CTL A Processor Diagnostics
Address
83 Floor zone
84 Position bypass count
85 Position pass count
86 System position count
87 Absolute position count
88 Position lower sequence
89 Position upper sequence
90 Position lower value
91 Position upper value
92 Landing code
93 At landing
95 Near floor
Port A inputs:
01 = (n/a)
02 = (n/a)
03 = (n/a)
04 = MHDBR
05 = (n/a)
06 = (n/a)
07 = FRA
100 08 = FRON
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = FRSM
14 = FRS
15 = (n/a)
16 = (n/a)
Port B inputs:
01 = HDBO
02 = M2MV
03 = FRES
04 = CDBO
05 = MGB
06 = INA
07 = INN
101 08 = INCP
09 = MGS
10 = ICTD
11 = ICTU
12 = INCT
13 = MREN
14 = MRIN
15 = MRUP
16 = MSAFS1
5-80 Manual # 42-02-1P21
Item Notes
