Table 5.14 Controller Board CTL A Processor Diagnostics
Address
41 Speed @ UNTS2 over-speed fault
42 Speed @ UNTS3 over-speed fault
43 Speed @ UNTS4 over-speed fault
44 Speed @ UNTS5 over-speed fault
45 Runtime distance @ DETS
46 Runtime distance @ DNTS1
47 Runtime distance @ DNTS2
48 Runtime distance @ DNTS3
94 Runtime distance @ DNTS4
50 Runtime distance @ DNTS5
51 Runtime distance @ UETS
52 Runtime distance @ UNTS1
53 Runtime distance @ UNTS2
54 Runtime distance @ UNTS3
55 Runtime distance @ UNTS4
56 Runtime distance @ UNTS5
57 Distance @ DETS position fault
58 Distance @ DNTS1 position fault
59 Distance @ DNTS2 position fault
60 Distance @ DNTS3 position fault
61 Distance @ DNTS4 position fault
62 Distance @ DNTS5 position fault
63 Distance @ UETS position fault
64 Distance @ UNTS1 position fault
65 Distance @ UNTS2 position fault
66 Distance @ UNTS3 position fault
67 Distance @ UNTS4 position fault
68 Distance @ UNTS5 position fault
69 DETS type
70 DTS1 type
71 DNTS2 type
72 DNTS3 type
73 DNTS4 type
74 DNTS5 type
75 UETS type
76 UNTS1 type
77 UNTS2 type
78 UNTS3 type
79 UNTS4 type
80 UNTS5 type
81 Successful runs
82 Fault runs
F5: Controller Utilities/Monitoring and Reporting
