Analog Devices ADSP-21160 EZ-KIT Lite System Manual page 88

A
1
VDD_EXT
C46 C47 C55 C56 C57 C59
10UF 10UF 0.1UF 0.1UF 0.1UF 0.1UF
1210 1210 805 805 805 805
ADSP-21160N (U1)
2
A5V
CT11 C44
0.01UF
1UF
A 805
AGND
SSM2135 (U?)
3
CT21 C107 C106
0.01UF 0.01UF
10UF
B 805 805
4
A
B
C66 C60 C63 C62 C65 C54
0.1UF 0.1UF 0.1UF 0.01UF 0.01UF 0.01UF
805 805 805 805 805 805
3V
3V
C69 C67 C68 C70
0.1UF 0.1UF 0.1UF 0.01UF
C45
0.1UF
805 805 805 805
805
MT58L64L32 (U8)
OSC (U2)
3V
C38 C32 C39 C97 C103 C104
0.01UF 0.01UF 0.01UF 0.01UF 0.01UF 0.01UF
805 805 805 805 805 805
CYC64603-128 (U11)
B
VDD_INT
C48 C49 C98 C34 C95 C93 C88
10UF 10UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF
1210 1210 805 805 805 805 805
ADSP-21160N (U1)
3V 3V
C73 C71 C72 C74
0.1UF 0.1UF 0.1UF 0.01UF
C83
0.01UF
805 805 805 805
805
MT58L64L32 (U9) IDT74FCT3244APY (U6)
3V 3V
C96 C31
0.01UF 0.01UF
C105
0.01UF
805 805
805
SN74LV164A (U17) CY7C1019V33-15VC (12)
C
C92 C90 C91 C89 C100 CT9
0.1UF 0.1UF 0.01UF 0.01UF 0.01UF
10UF
805 805 805 805 805 B
AD1885JST DIGITAL (U10)
3V 3V
C78
0.01UF
C84 C85
0.01UF 0.01UF
805
805 805
74LVC00AD (U5) ADM708SAR (U4) 74LVC14A (U7)
3V 3V 3V
C30 C116 C109 C108 C61
0.01UF 0.01UF 0.01UF 0.01UF 0.01UF
805 805 805 805 805
SN74AHC1G00 (U26) SN74AHC1G02 (U16) 74LVC14A (U19) QS3257 (U14, U15)
ANALOG
DEVICES
Title
Approvals Date
ADSP-21160 EZ-KIT LITE - BYPASS CAPS
Drawn
Size Board No.
Checked
C
Engineering
Date
5-2-2002_14:26
C
D
A5V
3V
CT10 C53 C82 C64
C86 C87
0.01UF 0.01UF 0.01UF
0.01UF 0.01UF 10UF
B 805 805 805
805 805
AGND
AD1885JST ANALOG (U10)
3V 3V
C75 C77
0.01UF 0.01UF
805 805
AT49BV040 (U7)
3V 3V 3V
C58 C94 C99
0.01UF 0.01UF 0.01UF
805 805 805
CY7C4201V-15AC (U18) 24LC00-SN (U25)
20 Cotton Road
Nashua, NH 03063
PH: 1-800-ANALOGD
A0164-2001
Sheet of
8
D
1
2
3
4
Rev
1.2
8
