Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
Table 3-10. P8 Part Number Information
Part Description
14-pin IDC Header (
Audio Connectors (P9–10)
There are two 3.5 mm stereo audio jacks: one input and one output.
Table 3-11. P9, P10 Part Number Information
Part Description
3.5 mm stereo jack (
3.5mm stereo plug to 3.5mm stereo
cable
SPORT0 Connector (P11)
links to a 20-pin connector. The pinout for this connector can be
SPORT0
found in
Appendix B,
Table 3-12. P11 Part Number Information
Part Description
20-position AMPMODU system 50
receptacle (
)
P11
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Manufacturer
)
Berg
P8
Manufacturer
and
)
Shogyo
P9
P10
Mating Connectors
Radio Shack
"Schematics".
Manufacturer
AMP
Mating Connector
EZ-KIT Lite Hardware Reference
Part Number
54102-T08-07
Part Number
SJ-0359AM-5
42-2387A
Part Number
104069-1
3-13
