ADSP-21160M EZ-KIT LITE

6 1 MMBT4401 SOT-23
NPN TRANSISTOR 200MA
7 1 74LVC00AD SOIC14
8 1 24LC00-SN SOIC8
128 BIT SERIAL EEPROM
9 1 CY7C1019BV33-15VC SOJ32
128K X 8 SRAM
10 1 AD8532AR SOIC8
DUAL AMP 250MA
11 1 SN74AHC1G02 SOT23-5
SINGLE-2 INPUT-NOR
12 1 SN74LV164A SOIC14
8-BIT-PARALLEL-SERIAL
13 1 CY7C4201V-15AC TQFP32
64-BYTE-FIFO
14 1 12.0MHZ THR OSC006
CRYSTAL
15 1 SN74AHC1G00 SOT23-5
SINGLE-2-INPUT-NAND
16 2 MT58L64L32 TQFP100_B
64KX32-SBSRAM
17 1 LT1765 SO-8
ADJUST-
ABLE-3A-SWITCH-REG
18 1 40MHZ SMT OSC003
19 2 1000pF 50V 5% 1206
CERM
A-2
Q1
U5
U25
U12
U10
U16
U17
U18
Y3
U26
U8–9
VR3
U2
C40, C42
ADSP-21160 EZ-KIT Lite Evaluation System Manual
FAIR- MMBT4401
CHILD
PHILIPS 74LVC00AD
MICRO- 24LC00-SN
CHIP
CYPRESS CY7C1019BV33-12VC
ANALOG AD8532AR
DEVICES
TI SN74AHC1G02DBVR
TI SN74LV164AD
CYPRESS CY7C4201V-15AC
DIG01 300-6027-ND
TI SN74AHC1G00DBVR
MICRON MT58L64L32FT-10
LINEAR LT1765ES8
TECH
DIGIKEY SG-8002CA-PCC-ND40.0
MHZ
AVX 12065A102JAT2A
