ADSP-21160N EZ-KIT Lite

1 1 M29W040 PLCC32
FLASH-512K-X-8-3V
2 2 74LVC14A SOIC14
HEX-INVER-SCHMITT-TRI
GGER
3 1 IDT74FCT3244APY SSOP20
3.3V-OCTAL-BUFFER
4 1 24.576MHZ SMT OSC005
CRYSTAL
5 1 CY7C64603-128 PQFP128
USB-TX/RX MICROCON-
TROLLER
ADSP-21160 EZ-KIT Lite Evaluation System Manual
JP1 BERG
P8 BERG
SJ1–2 MOLEX
F1 RAYCHEM
CORP.
P9–10
U3 ST MICRO
U7, U19 TI
U6 IDT
Y1 EPSON
U11 CYPRESS
Bill Of Materials
54102-T08-03
54102-T08-07
15-38-1024
SMD250-2
M29W040B120K6
74LVC14AD
IDT74FCT3244APY
MA505 24.576M-C2
CY7C64603-128NC
