Levelflex M FMP41C, FMP45
Operation concept
Display elements
Endress+Hauser
Human interface
The display of the process value and the configuration of the Micropilot occur locally by means of a large 4-line
alphanumeric display with plain text information. The guided menu system with integrated help texts ensures
a quick and safe commissioning.
To access the display the cover of the electronic compartment may be removed even in hazardous area (IS and
XP).
Remote commissioning, including documentation of the measuring point and in-depth analysis functions, is
supported via the ToF Tool, the graphical operating software for E+H time-of-flight systems.
Liquid crystal display (LCD):
Four lines with 20 characters each. Display contrast adjustable through key combination.
EN
EN
Orde
Orde
MIC
MIC
DR
DR
ESS
ESS
Ser.-
Ser.-
r Code
r Code
RO
RO
PIL
PIL
+HA
+HA
No.:
No.:
:
:
OT
OT
US
II
US
II
ER
ER
Mess
Mess
Meas
Meas
uring
berei
berei
uring
ch
ch
U 16...3
U 16...3
range
range
max.
max.
4...20
4...20
6 V
6 V
20
m
20
m
mA
mA
DC
DC
IP
IP
65
65
A
T
A
T
>70°C
>70°C
:
t >85°C
t >85°C
:
The VU331 LCD display can be removed to ease operation by simply pressing the snap-fit (see graphic above).
It is connected to the device by means of a 20" (500 mm) cable.
The following table describes the symbols that appear on the liquid crystal display:
Sybmol
Meaning
ALARM_SYMBOL
This alarm symbol appears when the instrument is in an alarm state. If the symbol flashes, this indicates a
warning.
LOCK_SYMBOL
This lock symbol appears when the instrument is locked,i.e. if no input is possible.
COM_SYMBOL
This communication symbol appears when a data transmission via e.g. HART, PROFIBUS PA or
FOUNDATION Fieldbus is in progress.
SIMULATION_SWITCH_ENABLE
This communication symbol appears when simulation in FOUNDATION Fieldbus is enabled via the DIP
switch.
LCD
(liquid crystal display)
Symbols
ENDRESS + HAUSER
–
+
E
3 keys
snap-fit
L00-FMxxxxxx-07-00-00-en-001
33
