Levelflex M FMP41C, FMP45

Process temperature range

Process pressure

Materials used in the process

Endress+Hauser

Operating conditions: Process

The maximum permitted temperature at the process connection (see figure measuring point) is determined by
the process connection ordered:
FMP41C
Min. temperature Max. temperature
-40°F (-40°C) 392°F (+200°C)
For FMP41C with E+H universal adapter: 32°F to 302°F (0°C to 150°C).
FMP45
Pressure psi
FMP45: process pressure depending on the process temperature
(bar)
6530 (450)
5800
(400)
5800 (400)
5075 (350)
4350 (300)
3625 (250)
2900 (200)
2175 (150)
1450 (100)
725 (50)
0
-328 -148
(-200) (-100)
FMP41C
All models: Vacuum up to max. 585 psi (40 bar).
For FMP41C with E+H universal adapter: max. 87 psi (6 bar).
For FMP41C with Clamp see ordering Information on → Page 40.
FMP45
See pressure/temperature diagram on this page.
The specified rage may be reduced by the selected process connection.
The pressure rating (PN) specified on the flanges refers to a reference temperature of 20°C, for ASME flanges
to 100°F.
PFA
2 mm
TFM 1600
(0.08")
32 212
(0) (100)
Cable probe
1.4401 / PFA
0.75 mm PFA
PFA PFA
(0.03") 2 mm
Measured
here
5510
(380)
5075
(350)
4350
(300)
FMP45 XT FMP45 HT
392 572 752
(200) (300) (400)
536
Temperature °F
(280)
(°C)
Rod probe
PFA
TFM 1600 2 mm
PFA
(0.08")
L00-FMP45xxx-05-00-00-en-001
PFA
L00-FMP4xxxx-16-00-00-en-002
27
