Ordering structure Levelflex M FMP41C
10 Approval:
A Non-hazardous area
F Non-hazardous area, WHG
1 ATEX II 1/2G EEx ia IIC T6
Note safety instruction (XA) (electristatic charging)!
3 ATEX II 2G EEx em (ia) IIC T6
Note safety instruction (XA) (electristatic charging)!
5 ATEX II 1/2G EEx ia IIC T6, ATEX II 1/3D
Note safety instruction (XA) (electristatic charging)!
6 ATEX II 1/2G EEx ia IIC T6, WHG
Note safety instruction (XA) (electristatic charging)!
7 ATEX II 1/2G EEx d (ia) IIC T6
Note safety instruction (XA) (electristatic charging)!
8 ATEX II 1/2G EEx ia IIC T6, ATEX II 1/3D, WHG
Note safety instruction (XA) (electristatic charging)!
G ATEX II 3G EEx nA II T6
S FM IS Cl.I,II,III Div.1 Gr.A-G N.I.
T FM XP Cl.I,II,III Div.1 Gr.A-G
N CSA General Purpose
U CSA IS Cl.I,II,III Div.1 Gr.A-D,G + coal dust, N.I.
V CSA XP Cl.I,II,III Div.1 Gr.A-D,G + coal dust, N.I.
K TIIS Ex ia IIC T4
L TIIS Ex d (ia) IIC T5
Y Special version
20 Probe:
A ..... mm, cable PFA>316, 150mm, Center rod, nozzle height max 150mm
B ..... mm, cable PFA>316, 300mm, Center rod, nozzle height max 300mm
C ..... mm, cable PFA>316, 450mm, Center rod, nozzle height max 450mm
D ..... inch, cable PFA>316, 6inch, Center rod, nozzle height max 6inch
E ..... inch, cable PFA>316, 12inch, Center rod, nozzle height max 12inch
G ..... inch, cable PFA>316, 18inch, Center rod, nozzle height max 18inch
K ..... mm, rod PFA>316L
M ..... inch, rod PFA>316L
Y Special version
30 Process Connection:
AEK 1-1/2" 150lb, PTFE >316/316L flange ASME B16.5
AFK 2" 150lb, PTFE >316/316L flange ASME B16.5
AGK 3" 150lb, PTFE >316/316L flange ASME B16.5
AHK 4" 150lb, PTFE >316/316L flange ASME B16.5
AJK 6" 150lb, PTFE >316/316L flange ASME B16.5
AQK 1-1/2" 300lb, PTFE >316/316L flange ASME B16.5
ARK 2" 300lb, PTFE >316/316L flange ASME B16.5
ASK 3" 300lb, PTFE >316/316L flange ASME B16.5
ATK 4" 300lb, PTFE >316/316L flange ASME B16.5
CEK DN40 PN16-40, PTFE >316L flange EN1092-1 (DIN2527 C)
CFK DN50 PN10-40, PTFE >316L flange EN1092-1 (DIN2527 C)
CGK DN80 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CHK DN100 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CJK DN150 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CSK DN80 PN25/40, PTFE >316L flange EN1092-1 (DIN2527 C)
CTK DN100 PN25/40, PTFE >316L flange EN1092-1 (DIN2527 C)
KEK 10K 40, PTFE >316L flange JIS B2220
KFK 10K 50, PTFE >316L flange JIS B2220
KGK 10K 80, PTFE >316L flange JIS B2220
KHK 10K 100, PTFE >316L flange JIS B2220
FMP41C- Product designation (part 1)
