Equipment architecture

4
Output
The Levelflex is initially adjusted at the factory to the probe length ordered, so that in most cases, only the
application parameters that automatically adapt the device to the measuring conditions need to be entered. For
models with current output, the factory adjustment for zero point E and span F is 4 mA and 20 mA; for digital
outputs and the display module, 0 % and 100 %.
A linearization function with maximum 32 points, that is based on a manually or semi-automatically input
table, can be activated locally or via remote operation. This function enables, for example, the conversion of
the level signal into units of volume or weight.
Probe selection
The various types of probe in combination with the process connections are suitable for the following
applications:
FMP41C
Completely coated probes for measurement in corrosive/chemically aggressive liquids.
Version:
Type of probe:
Wetted materials:
Other materials:
Tensile loading capacity
(min.):
Lateral loading capacity:
Application for:
Probe length:
FMP41C- *K...
FMP41C- *L...
Rod probe
Rod and cable: PFA
Flange plating: PTFE (TFM 1600)
Housing: see Ordering information
Flange and housing adapter: 316L SS/1.4435
Not relevant
22 lbf ft (30 Nm)
• corrosive liquids
• liquids in the foods/
pharmaceutical sector
1 to 13 ft (0.3 to 4 m)
Levelflex M FMP41C, FMP45
FMP41C- *A...
FMP41C- *B...
FMP41C- *C...
FMP41C- *D...
FMP41C- *E...
FMP41C- *G...
Cable probe
450 lbf (2000 N)
Not relevant
• corrosive liquids
3 to 100 ft (1 to 30 m)
