Installation for difficult to
access process connections
wall
3.70"
(94)
Max. Pipe
diameter
3" (80)
Min. 1.2" (30)
3.78"
(96)
24
Installation with remote housing
• Follow installation instructions on → Page 19.
• Mount the housing on the wall or pipe (in vertical or horizontal position as required) as shown in the
diagram.
2.26" 3.07"
(65) (78)
Ø 5.08"
ENDRESS+HAUSER
Levelflex M
(129)
5.91"
(150)
3.35"
(85)
2.05"
(52)
ENDRESS+HAUSER
Levelflex M
3.70" 3.70"
(94) (94)
Note!
The protective hose cannot be disassembled at these points (1).
The ambient temperature for the connecting line (2) between the probe and electronics can be max. 105°C.
FMP45: For the remote electronics, temperatures up to 536°F (280°C) or 752°F (400°C), depending on the
instrumeent version) are admissible at the process connection.
The version with remote electronics consists of the probe, a connecting cable and the housing. If they are
ordered as a set, they are assembled on delivery.
3.46"
(88)
3.46"
4 x Ø 0.33"
(88)
(8.5)
Ø 0.84"
(21.3)
Refer to housing
dimensions above
Levelflex M FMP41C, FMP45
1
2
Note min.
bend radius!
7.48"
(190)
1
1
Ø 2.99"
(76)
5.91"
(150)
4.84"
(123)
108"
(2765)
4.41"
(112)
L00-FMP4xxxx-17-00-00-en-015
