Endress+Hauser Levelflex M FMP41C Technical Information page 41

Levelflex M FMP41C, FMP45
Endress+Hauser
Ordering structure Levelflex M FMP41C (continued)
30 Process Connection:
MRK DIN11851 DN50 PN40, PTFE >316L
TCK Clamp ISO2852 1-1/2", PTFE >316L
TDK Clamp ISO2852 2", PTFE >316L
TFK Clamp ISO2852 3", PTFE >316L
TJK Clamp ISO2852 1-1/2", PTFE >316L
TKK DRD 65mm PN40, PTFE >316L
TLK Clamp ISO2852 2", PTFE >316L, 3-A EHEDG
TNK Clamp ISO2852 3", PTFE >316L, 3-A EHEDG
UPK Adapter 44mm, PTFE >316L
UQK Adapter 44mm, PTFE >316L, EHEDG 3-A
YY9 Special version
40 Power Supply; Output:
B 2-wire; 4 to 20mA HART
D 2-wire; PROFIBUS PA
F 2-wire; FOUNDATION Fieldbus
G 4-wire 90 to 250VAC; 4 to 20mA HART
H 4-wire 10.5 to 32VDC; 4 to 20mA HART
Y Special version
50 Operation:
1
2
3
9
60
70
80
90
FMP41C-
⇓
Please enter probe length in mm or inch / 0.1 inch
Probe length LN → Page 30
W/o display, via communication
4-line display VU331, Envelope curve display on site
Prepared for FHX40, Remote display (accessory)
Special version
Type of Probe:
1 Compact, basic version
3 Remote, cable 3m, top entry
4 Remote, cable 3m, side entry
9 Special version
Housing:
A F12 Alu, coated IP68 NEMA6P
B F23 316L IP68 NEMA6P
C T12 Alu, coated IP68 NEMA6P, Separate conn. compartment
D T12 Alu, coated IP68 NEMA6P + OVP, Separate conn. compartment,
OVP = overvoltage protection
Y Special version
Cable Entry:
2 Gland M20 (EEx d > thread M20)
3 Thread G1/2
4 Thread NPT 1/2"
5 Plug M12
6 Plug 7/8"
9 Special version
Additional Option:
A Basic version
Y Special version
Complete product designation
mm
inch / 0.1 inch
41
