Remote display FHX40

F12/F23 housing
NEMA 6P (IP 68)
E N E N
D R D R
E S E S
O rd O rd
S + S +
er er
S er S er C od C od H A H A
e: e: U S U S
.- N .- N
o. : o. : E R E R
M es M es
sb er sb er
M ea M ea
ei ch ei ch
su rin su rin
g ra g ra
ng e ng e
U 16 U 16
m ax m ax
... 36 ... 36 . 20 . 20
4. ..2 4. ..2
0 m 0 m V D V D m m
C C
A A
IP
6 5
T T
A A
> 70 > 70
°C °C
: :
t >8 t >8
5° C 5° C
46
(without mounting bracket)
4.8"
(122)
3.2"
(80)
0.25"
(6.3)
Technical data (cable and housing) and product structure:
Max. cable length
Temperature range
Degree of protection
Materials
Dimensions inches (mm)
Approval:
A Nn-hazardous area
1 ATEX II 2 G EEx ia IIC T6, ATEX II 3D
S FM IS Cl.I Div.1 Gr.A-D
U CSA IS Cl.I Div.1 Gr.A-D
N CSA General Purpose
K TIIS ia IIC T6 (in preparation)
Cable:
1 20m/65ft; for HART
5 20m/65ft; for PROFIBUS PA/FOUNDATION Fieldbus
Additional option:
A Basic version
B Mounting bracket, pipe 1"/ 2"
FHX40 - Complete product designation
For connection of the remote display FHX40 use the cable which fits the communication version of the
respective instrument.
Wall-mounting
Remote housing
5.9"
(150) FHX 40 NEMA 4
(IP 65)
Cable
4.72"
(120)
3.23"
(82)
4.17"
(106)
4.80"
(122)
20 m (65 ft)
-22 to +158 °F (-30 to +70°C)
IP65 acc. to EN 60529 (NEMA 4)
Housing: AlSi12; cable glands: nickle plated brass
4.8 x 5.9 x 3.2 (122 x 150 x 80), HxWxD
Levelflex M FMP41C, FMP45
Pipe-mounting
(mounting bracket and plate
supplied optionally, see product structure)
0.33"
(8.5)
7.09"
(180)
6.3"
(160)
3.46"
(88)
4.65"
(118)
3.78"
(96)
max.
3.15" (80)
min.
1.18" (30)
Pipe
Endress+Hauser
L00-FMxxxxxx-00-00-06-en-003
