Main SP Tables-6

SP6-XXX (Peripherals)

6006 [ADF Adjustment]
6-006-001 Main Scan: Regist: Front
Side
6-006-002 Main Scan: Regist: Rear
Side
6-006-003 Sub Scan: Regist: Front Side
6-006-004 Sub Scan: Regist: Rear Side
6-006-007 Trailing Edge Erase Width
6007 [ADF INPUT Check]
6-007-009 Original Detection Sensor
6-007-013 Registration Sensor
6-007-015 Feed Cover Sensor
6-007-016 Lift-up Sensor
6008 [ADF OUTPUT Check]
6-008-003 Feed/Relay Motor FWD
Rotation
6-008-004 Feed/Relay Motor RVS
Rotation
6-008-009 Feed Clutch
6-008-011 Reverse Solenoid
6011 [ADF INPUT Check]
6-011-004 DF_WSS_1
ENG* [-3 to 3 / 0 / 0.1 mm / step]
ENG* [-3 to 3 / 0 / 0.1 mm / step]
ENG* [-5 to 5 / 0 / 0.1 mm / step]
ENG* [-5 to 5 / 0 / 0.1 mm / step]
ENG* [-5 to 5 / -3 / 0.1 mm / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
ENG [0 or 1 / 0 / 1 / step]
Main SP Tables-6
95
