4. Replacement and Adjustment
3.
Separate the sheet, bracket, and friction pad [A].
DFRB (DF Relay Board)
1.
ARDF Rear Cover
2.
DFRB [A]
• There is a tab holding the DFRB [A].
ARDF Feed Cover Sensor, Original Set Sensor
1.
ARDF Rear Cover
2.
Remove the following:
1. ARDF Feed Cover Sensor [A]
2. Original Set Sensor [B]
168
(page
161)
(page
161)
