Element Multi Testing Meter; Element Multi Testing Meter Display - Infopia ELEMENT MULTI Instructions For Use Manual

Element Multi Testing Meter

Glucose Test Strip Port
lnsert the glucose test strip
Glucose test Strip Ejector
Strip discard function by pushing toward outside
LCD Screen
Display measurement level of glucose, TC, HDL, TG and
Cacluated LDL including time and message
Up (▲) button
Button for memory mode and choice of function in each
mode.
Down (▼) button
Button for choice of function in each mode & Printer
operation button.
Mode (
Setting mode, Cholesterol measurement mode, On and
Off button & RFID mode.
RFID (
Part for placing the RFID-tag on the strip bottle
cholesterol Testing part
cholesterol test strip inserting part
Buzzer sound print part
Printing part for warning sound, fixed sound and buzzer
sound
Battery Cover
Purpose for Battery replacement and fixed cover
Caution
1. Do not use Element Multi meter in a dry environment, especially if synthetic
materials are present. Synthetic clothes, carpets, etc., may cause damaging static
discharges in a dry environment.
2. Do not use Element Multi meter near cellular or cordless telephones, walkie talkies,
garage door openers, radio transmitters, or other electronic or electrical equipment
that are sources of electromagnetic radiation, as these may interfere with the proper
operation of the meter.
) button
) Printing part
• 08 •

Element Multi Testing Meter Display

Blood Glucose
Total cholesterol
Triglyceride
HDL-cholesterol
LDL-cholesterol
Blood insertion for glucose test
Blood insertion for cholesterol test
Serum
Sample blood
Displaying code number of Test Strips
Low batteries
Alarm
Testing unit
Temperature & date of test
Hour & Date of test
Average Test Results(only for glucose)
Control Solution Symbol
Day & Month
Year
• 09 •
