7847i/7847i-E Installation and Setup Guide

Using the Tamper Switch

Initiate the registration sequence by clicking the Tamper Switch three times.
You can monitor the registration process by viewing the Status Display. The Message
(yellow) LED and the Status (green) LED will blink slowly in unison while the registration is
in progress.
Once the registration has been completed successfully, the 7847i/7847i-E enters normal
operating mode; the Status (green) LED goes out and the Message (yellow) LED is lit to
indicate that the power-on / reset message is waiting to be sent. This message will appear at
the receiving station as "E339 8xx", where "xx" is the ECP device address. The description
may read "Trouble – Exp. Mod. Reset". If registration is not validated within 90 seconds, the
unit times out, and the (green) LED will be lit (solid).
If repeated registration attempts time out, check your Internet connection and verify that
7847i/7847i-E account information has been entered correctly.
The power-on/reset message will be sent in Ademco High-Speed format if the module is
programmed for zone trigger, 4204 or 2x4204 modes.

Using the Programming Tool

The interactive registration feature allows the installer to register the 7847i/7847i-E through
a series of keyboard commands on the 7720P Programming Tool. This method of registration
lets the installer monitor the registration process.
4-2
Registering ...
Registration
SUCCESS
Possible Errors When Configured for Private LAN
Function
Unavailable
No Registration
Account Disabled
Registration BAD
Timed Out
Registration BAD
Account Exists!
Registration BAD
CS Database FULL
Registration BAD
Once the installation is complete, press the [↑] key on
the 7720P. The registration message is sent and the unit
waits for the acknowledgment.
If this is a new installation and the city, central station,
and customer numbers have been correctly entered, the
7847i/7847i-E is registered and this message is
displayed. The unit is now in full service and available
for alarm reporting to the central station.
The Installation Key MUST be programmed in order to
initiate the Registration process.
This message will be displayed if the key is invalid.
Account was disabled at the 7810iR-ent prior to the
registration attempt or while registration was in
progress.
If the Registration Key entered is invalid, this message
is displayed.
This prompt is displayed if the account number
programmed in the 7847i-E is already being used for a
different 7847i-E in the system. If a replacement is
desired, enable Substitution Mode in the 7810iR-ent.
This prompt is displayed if the 7810iR-ent receiver has
reached its maximum capacity for accounts. Its
database is limited to 300 subscribers.
This prompt is displayed if a general problem occurred
when the 7847i-E tried to register with the 7810iR-ent.
