Mixing and Control
As stated in the
are set for optimal signal levels, mixing and further run‑time level control can be performed
from the Mix Tab.
Program and Far End Mix
In Figure 7, gain control locations are shown for the following mix controls:
Program Mix
•
•
•
From Far End
•
USB PLAYBACK L
GAIN
USB PLAYBACK R
GAIN
HDMI IN L
GAIN
HDMI IN R
GAIN
LINE IN L
GAIN
LINE IN R
GAIN
USB COMMUNICATIONS L
GAIN
USB COMMUNICATIONS R
GAIN
MIC/LINE IN
GAIN
Figure 7.
The signals associated with these four controls comprise the mix that is sent to the
MediaPort Line Out. The Program Mix audio, minus the From Far End audio (USB
Communications), comprise the mix that is sent to the USB Out.
Audio Application Setup
USB Playback
HDMI
Line In
USB Communications
FLT
COMP
GAIN
FLT
COMP
GAIN
FLT
COMP
GAIN
FLT
COMP
GAIN
FLT
COMP
GAIN
FLT
COMP
GAIN
FLT
COMP
DUCKER
GAIN
FLT
COMP
DUCKER
GAIN
FLT
COMP
DUCKER
GAIN
Gain Control Locations
MediaPort 200 Audio Application Tutorial • MediaPort 200 Signal Flow
section on page 1, once the input gain controls
PROGRAM MIX
USB
HDMI
LINE IN
PLAYBACK
MUTE
MUTE
MUTE
FROM FAR END
USB COMMUNICATIONS
SEND TO
AEC Ref + Line Out
AEC Ref Only
MUTE
15
