Configurations for
DMP 128
Applications #2 and #4, described in the
the user guide, utilize a DSP matrix processor with AEC to add additional microphones to
a conferencing system. Detailed instructions for using an Extron DMP 128 C model DSP
processor with the MediaPort 200 are provided in this section. A DSP Configurator template
file with pre‑configured routing and control points is available on the Extron website,
making it extremely easy to configure and use a DMP 128 C (herein referred to as
DMP 128). Troubleshooting will also be simplified, should it be necessary to contact Extron.

Routing for Application #2

Mic Inputs 1 – 8
•
•
•

Program L/R Inputs 9 and 10

Program content comes from the MediaPort 200 Line Output L/R, which is a mix of the
USB Playback, HDMI, and Line Input signals.
•
•
•
Microphone inputs are routed to the Virtual Send A, using the "Include Automixing"
routing option.
From Virtual Return A, the Mic Mix is routed to Output 3. DMP 128 Output 3 is
connected to the MediaPort 200 Mic/Line Input.
In the DMP 128 AEC processing dialog, "AEC Ref (Virtual Return #H)" is assigned as
the AEC reference for mic inputs 1 – 8.
MediaPort 200 Line Output L/R is connected to the DMP 128 Inputs 9 and 10 "MP
Program L/R."
DMP 128 Inputs 9 and 10 are routed to Outputs 1 and 2, and then connected to a
stereo sound reinforcement system in the room.
DMP 128 Inputs 9 and 10 are routed to Virtual Send H for the AEC reference.
