Privacy Mute — Master Mute
A master mute control for the microphone mix is located at the Virtual Return A pre‑mixer
gain point, labeled "Privacy Mute." This control mutes the mic mix routed to Output #3,
connected to the MediaPort 200 Mic/Line Input, and ultimately to the far end of a soft codec
conference. This control can be used for privacy during a conference call, to mute the near
end mics going to the far end while still being able to hear the far end.

Group Masters

The following is a list of groups for Application #4. Mute groups align vertically with the
corresponding gain group that controls volume.
Group Name
Program (fader)
Program (mute)
Far End (fader)
Far End (mute)
Video Codec (fader)
Video Codec (mute)
Privacy Mute
Figure 16.
Group Description
Number
2 Volume control for program audio to local room
13 Mute control for program audio to local room
3 Volume control for far end audio (from MediaPort) to
local room
14 Mute control for far end audio (from MediaPort) to local
room
4 Volume control for video codec audio to local room
15 Mute control for far end audio to local room and
MediaPort
12 Mutes local mics for private discussion
Application #4 Group Controls
MediaPort 200 Audio Application Tutorial • Configurations for DMP 128 29
