Event Lighting PANBEAM4x4x10 User Manual page 7

8 000-255
000-009
010-070
9 071-132
133-194
195-255
16 Channels Mode: 4x1 Model
CHANNEL VALUE
1,5,9,13 000-255
2,6,10,14 000-255
3,7,11,15 000-255
4,8,12,16 000-255
64 Channels Mode: 4x4 Model
CHANNEL VALUE
1 000-255
2 000-255
3 000-255
4 000-255
7
Speed of Auto Programs (Slow ~
Fast)
Default dimmer speed
Non-linear dimmer 1
Non-linear dimmer 2
Non-linear dimmer 3
Non-linear dimmer 4
FUNCTION
Red 0% ~ 100%
Green 0% ~ 100%
Blue 0% ~ 100%
White 0% ~ 100%
FUNCTION
Red 0% ~ 100%
Green 0% ~ 100%
Blue 0% ~ 100%
White 0% ~ 100%
LED 1 (1-4), LED 2 (5-8), LED 3 (9-12),
LED 4 (13-16)
LED 1 (1-4), LED 2 (5-8), LED 3 (9-12),
LED 4 (13-16), LED 5 (17-20), LED 6
(21-24), LED 7 (25-28), LED 8 (29-32),
LED 9 (33-36), LED 10 (37-40), LED 11
(41-44), LED 12 (45-48), LED 13
(49-52), LED 14 (53-56), LED 15
(57-60), LED 16 (61-64),
