System maintenance switch
Position
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
You can access the redundant ROM by setting S1, S5, and S6 to On.
When the system maintenance S6 switch is set to the On position, the system will erase all system
configuration settings from both CMOS and NVRAM on the next reboot. Clearing CMOS, NVRAM, or
both delete configuration information. Be sure to configure the server properly to prevent data loss.
NMI functionality
An NMI crash dump creates a crash dump log before resetting a system which is not responding.
Crash dump log analysis is an essential part of diagnosing reliability problems, such as failures of
operating systems, device drivers, and applications. Many crashes freeze a system, and the only
available action for administrators is to restart the system. Resetting the system erases any information
which could support problem analysis, but the NMI feature preserves that information by performing a
memory dump before a system reset.
Description
System maintenance switch
TPM connector
NMI header
Dedicated iLO port connector
Slot 5 PCIe3 x8 (8, 4, 1)
Slot 4 PCIe3 x4 (4, 1)
microSD card slot
Slot 3 PCIe3 x8 (8, 4, 1)
Slot 2 PCIe3 x4 (4, 1)
Slot 1 PCIe3 x16 (16, 8, 4, 1)
Default
Function
Off
Off = iLO 4 security is enabled.
On = iLO 4 security is disabled.
Off
Off = System configuration can be
changed.
On = System configuration is locked.
Off
Reserved
Off
Reserved
Off
Off = Power-on password is enabled.
On = Power-on password is disabled.
Off
Off = No function
On = ROM reads system
configuration as invalid.
Off
Off = Set default boot mode to UEFI.
On = Set default boot mode to
legacy.
Reserved
—
—
Reserved
—
Reserved
—
Reserved
—
Reserved
