Hot-Plug Drive; 4-Bay Lff Hot-Plug Drive Cage - HPE ProLiant ML110 Gen9 Maintenance And Service Manual

o
Hot-plug SFF drive blank
To replace the SFF drive blank, while pressing the release latch, slide the component into the
bay until it is fully seated.

Hot-plug drive

CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
To remove the component:
Back up all server data on the drive.
1.
Remove the front bezel (on page 25).
2.
Determine the status of the drive from the drive LED definitions
3.
on page 82).
Remove the hot-plug drive.
4.
To replace the component, reverse the removal procedure.

4-bay LFF hot-plug drive cage

("Hot-plug drive LED
Removal and replacement procedures 30
definitions"
