6 THEORY OF OPERATION

FIRMWARE

6.2 FIRMWARE
All mathematical, logic and control functions are performed on an 80C32 microcomputer by a program stored
on a separate EPROM. The program execution flow is shown in the firmware block diagram of Figure 6–2:
FIRMWARE BLOCK DIAGRAM on page 6–4.
Every 2 ms the system clock generates an interrupt. At this time all timers are updated, the keypad is read and
debounced, and five A/D conversions are performed by the A/D module. These conversions are the ground
fault current reading, three phase current readings, and a single RTD, voltage reference, or power fail circuit
reading. At this point the RMS values of the currents are calculated, and short circuit and ground fault tests are
made. The EOC interrupt routine checks for a motor start condition and if this is true the phase sequence is
checked, a start timer is initiated, and the start register is updated.
The INITIALIZE module is performed whenever the relay is powered on to ensure that the system comes up in
a known state. Parts of this module are executed whenever the relay is reset as well. The SYSTEM EXECU-
TIVE then causes execution to loop through a series of modules which perform most of the relay functions.
The O/L module uses the positive to negative sequence current ratio calculated by the U/B module and the
RMS phase currents to fill a thermal memory register. The O/L module discharges this register at either a
learned or preset cooling rate when no overload is present. The average stator RTD temperature calculated in
the RTD module is used to bias the thermal memory. This module also compares the RMS phase current val-
ues to the Undercurrent and Rapid Trip/Mechanical Jam trip and alarm levels, and starts appropriate timers if
the current levels are out of range.
The U/B module computes the phase current ratios I / I and I / I
, and uses them in conjunction with a look-
b a c a
up table to determine the negative to positive sequence current unbalance ratio I / I . This value is compared
n p
to the Unbalance trip and alarm levels and appropriate timers are initiated if trip/alarm conditions are met.
The RTD module uses the RTD voltage reading from each of the 10 RTD inputs and uses the number of pro-
grammed stator RTDs to compute the average stator RTD temperature. This is then used to bias the thermal
memory. The RTD readings are compared to the trip and alarm levels and relay activation is initiated if condi-
tions are met. Each RTD is read 128 times over a 1 second scan interval.
6
The KEYSERVICE/EXTERNAL SWITCH module takes in all of the data associated with the keypad and exe-
cutes the function of each key. Timers for the closure times of the VALUE UP/DOWN, PAGE UP/DOWN, and
LINE UP/DOWN keys are initiated and the display is updated accordingly. This module also reads the Emer-
gency Restart, External Reset, Differential Relay, and Speed Switch inputs and initiates appropriate action.
The MESSAGE module handles all of the message look-up functions and sends the message data to the dis-
play. The displayed messages are made up of individual messages, common message strings, and variable
data. Non-displayed control bytes are used to indicate the message type, variable data type, decimal point
placement, and other control information.
The D/A module gives the DAC the current digital value for the selected option output for conversion to an ana-
log value. This analog voltage is then fed to a voltage-to-current converter circuit.
The SELF-TEST module causes the 80C32 to send out regular voltage signals to indicate to the power supply
watchdog circuit that the system is operating properly. This module also performs all of the self-test features
outlined in Section 3.25: RELAY SELF-TEST on page 3–65.
The TRIP/ALARM module is executed when any relay trip or alarm setpoint has been exceeded. This module
handles output relay activation and TRIP/ALARM message output.
Statistical data is updated whenever a statistical value changes.
GE Power Management 269Plus Motor Management Relay 6-
3
