ASSEMBLY INSTRUCTIONS
5.
Insert the edge of the offset lid bracket (Y) into
the slotted opening on the offset top section (W).
Attach using one M6 x 12 bolt (BB) and one
M6 nut (DD).
Hardware Used
BB
M6 x 12mm
Bolt
M6 Nut
DD
6.
Attach the offset bottom section (U) to the top
section (W) using six M6 x 12 bolts (BB).
Hardware Used
M6 x 12mm
BB
Bolt
x 1
x 1
x 6
8
5
Y
W
6
U
W
BB
DD
BB
