ASSEMBLY INSTRUCTIONS
11.
Rest the inner ring of the sausage hooks (C) on
the bottom brackets of the smoke stack (Z). Insert
the smoke stack (Z) up through the opening at the
top of the smoker body (A) and secure with three
M6 x 12 bolts (BB).
Hardware Used
BB
M6 x 12mm
Bolt
12.
Attach the smoke stack damper (A1) using the
preinstalled spring and nut.
x 3
12
11
11
A
Z
C
BB
A1
