ASSEMBLY INSTRUCTIONS
21.
Attach the offset damper plate (O) to the access
tray (T) using one M6 x 12 bolt (BB) and one
M6 lock nut (FF).
Hardware Used
M6 x 12mm
BB
Bolt
M6 Lock Nut
FF
22.
Place the charcoal grate (Q) inside the access
tray (T) and slide the tray into the offset smoker box.
21
x 1
x 1
22
16
FF
O
BB
Q
T
T
