How to use kit
Install all necessary accessories and apply your specimen to
MagCore®.
MAGCORE
STAND-BY
PRESS ( START ) TO RUN
Press START.
Initializing
After press Start button, machine runs program of calibration,
initialize to move all axis to original factory positions.
INPUT CARTRIDGE CODE
(3 DIGITALS)
(XXX)
Input Cartridge Code to run protocol.
Cartridge Code is shown on your Reagent Cartridge and the
cover of user manual.
!
Above CODE is for demonstration purpose, please refer
to the kit you purchase for proper program CODE.
INPUT CARTRIDGE CODE
(3 DIGITALS)
(OOO)
(Enter) NEXT PAGE
Confirm your input code again and press Enter to next page for
sample volume selection.
VIRAL NA OOO/OOO
SELECT SAMPLE VOLUME
(1)OOOul (2)OOOul
(ESC) PREV PAGE
Select Sample Volume.
CARTRIDGE CODE OOO
OOO...
(Enter) NEXT PAGE
(ESC) CANCEL
Confirm your input Sample Volume.
Press Enter for next page, Press ESC for back to Stand-By page.
www.rbcbioscience.com
3
MagCore®HF16 and Compact
At this step prepare racks to operation area.
After racks loaded then press Enter to next page for elution
volume selection.
Select final elution volume.
MagCore® in process of selected protocol at this step. The Green
Indicate LED lights up and Heating Block starts to heat up to
65°C for Lysis Step.
While MagCore® is under program running, the "MagCore" LCD
lights up at all times.
DO NOT open the door at this moment, it causes emergent stop
and you might lose your samples by machine interruption.
While program finished, a beep sound can be heard and Green
Indicate LED light went out.
Well Position of T-Rack
ENSURE RACKS LOADED
(1)CARTRIDGE RACK
(2)T-RACK
(ESC) PREV PAGE
SELECT ELUTE VOL
(1)OOOul (2)OOOul
(3)OOOul (4)OOO1ul
(ESC) PREV PAGE
ELUTE VOLUME OOOul
PREHEATING...
TmpOOOO...
PROCEDURE COMPLETED
(START)CONTUNUE
(STOP)STAND-BY
Well 1
Well 2
Well 3
Well 4
Elution Tube
Tip / Tip Holder
Sample Tube
