9.0

Appendix

9.1

Error Messages

The 880 indicator provides a number of error messages. When an error occurs, the message is shown on the
indicator display. Error conditions can also be checked remotely by using the XE EDP command as described in
Section 9.3.
9.1.1

Displayed Error Messages

The 880 provides a number of front panel error messages to assist in problem diagnosis. Table 9-1 lists these
messages and their meanings.
Error Message
¯ ¯ ¯ ¯ ¯ ¯
Over range
_ _ _ _ _ _
Under range
A/D out of range
Or if using local/remote (serial scale) -
(center dashes)
loss of serial scale data.
CFGERR Configuration error on power up if
there was an error loading
configuration
ERROR Internal program error
HWFERR Hardware failure error
• on failure to write to the EEPROM
• any error (except for a battery error
or an accumulation over range error)
when exiting the menu
LOBATT The low battery error flashes every 30
seconds when the battery is low.
NOTARE Tare is prevented because of
regulatory mode settings, the
configuration of the TAREFN
parameter, motion on the scale, etc.
RANGE A numeric value entered in
configuration is out of the acceptable
range. The error is displayed
momentarily – the parameter being
edited is then returned to so the value
can be corrected.
NO ZERO Zero is prevented (due to regulatory
mode settings. motion on the scale,
zero range settings)
Description
Check for improper load cell wiring, configuration, calibration, scale
hardware problems.
Press the Enter key to reboot the indicator.
Check configuration.
Press the Enter key to reboot the indicator.
Replace the battery.
Change regulatory mode settings or the TAREFN parameter.
Re-enter a value that is in range for the parameter being edited.
Check zero settings and for motion.
880
Table 9-1.
Solution
Error Messages
Appendix 79
