2.3

Connectors

2.3.1

AIIS-1200 External I/O Connectors

Front View
Rear View
AIIS-1200 User Manual
Thermal
HDD
VGA
LED
LED
Power
USB3.0
USB3.0
Buttton
Module
PoE 1/2
PoE
LED
Module
Line-out
Display
Mic-in
USB3.0
Port
Figure 2.1 AIIS-1200 I/O connectors
10
LAN1
COM1/2
On/Off
9V~36V
DIO
Port
DC
