User Manual
ARK-5260
Embedded IPC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARK-5260 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech ARK-5260

Summary of Contents for Advantech ARK-5260

  • Page 1 User Manual ARK-5260 Embedded IPC...
  • Page 2 English user manual included as a PDF file on the CD. Please disregard the Chinese hard copy user manual if the product is not to be sold and/or installed in China. ARK-5260 User Manual...
  • Page 3 The documentation and the software included with this product are copyrighted 2010 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 5 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 6 RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. ARK-5260 User Manual...
  • Page 7 Power cable 2-pin 180 cm, Europe 1700001949 Power cable 2-pin 180 cm, UK 1700018474 4-pin DC connector cable (compatible with 1960048412N001) 1960048412N001 4-Pin DC Bracket for ARK-5260 (compatible with 1700018474) 1757000537 AC-to-DC Adapter 4-Pin DC 19 V/6.32 A, 120 W ARK-5260 User Manual...
  • Page 8 ARK-5260 User Manual viii...

  • Page 9: Table Of Contents

    Ethernet ..................3 Chipset ...................... 3 1.3.1 Functional Specification ..............3 Mechanical Specifications................. 5 1.4.1 Dimensions ................... 5 Figure 1.1 ARK-5260 Mechanical Dimension Drawing....5 1.4.2 Weight................... 5 Power Requirement .................. 6 1.5.1 System Power................6 1.5.2 RTC Battery .................. 6 Environment Specification.................
  • Page 10 Figure 3.18Souh Bridge Configuration ........40 3.2.7 Exit Options ................41 Figure 3.19Exit Options .............. 41 Chapter Software installation......43 Driver Installation ..................44 4.1.1 Chipset driver installation............44 4.1.2 Graphic driver installation ............46 4.1.3 Audio Driver Installation.............. 49 ARK-5260 User Manual...
  • Page 11 Programming the Watchdog Timer ..........57 Table A.1: Watchdog Timer Registers ........58 A.1.4 Example Program ............... 59 Appendix B Programming the GPIO .....63 Supported GPIO Register ............... 64 B.1.1 GPIO Registers................64 B.1.2 GPIO Example Program ............. 65 ARK-5260 User Manual...
  • Page 12 ARK-5260 User Manual...

  • Page 13: Chapter 1 General Introduction

    Chapter General Introduction This chapter gives background information on ARK-5260.

  • Page 14: Introduction

    The ARK-5260 can be used as a standalone system or wall-mounted. The system accepts a wide range of DC power in and comes in a footprint of 137 x 189 x 221 mm.

  • Page 15: Ethernet

    Supports high-speed, full-speed, and low-speed capable Supports legacy keyboard/mouse software SB: Intel® ICH8M chip supports: Supports ACPI 3.0 Power ACPI Power Management Logic Support Management Power connector: Plug-In block 2P x 1 or DIN Jack 4P x1 ARK-5260 User Manual...
  • Page 16 Audio Connectors: Ear Phone Jack * 3 SMSC SCH 3106 support 10 I/O pins with one 5 V power ping and one ground pin 5 V tolerance I/Os. DIO Connectors: 9 pins DSUB connector Battery backup BR2032 3 V/195 mAh ARK-5260 User Manual...

  • Page 17: Mechanical Specifications

    Mechanical Specifications 1.4.1 Dimensions 137.0 [5.39] x 189.0 [7.44] x 221.0 [8.70] Unit: mm [Inch] 240.97 234.07 Figure 1.1 ARK-5260 Mechanical Dimension Drawing 1.4.2 Weight 4.2 kg (9.24 lbs) ARK-5260 User Manual...

  • Page 18: Power Requirement

    When system is equipped with Compact Flash card only: 50 G, IEC 60068-2-27, half sine, 11 ms duration. When system is equipped with 2.5-inch: 20 G, IEC 60068-2-27, half sine, 11 ms duration. 1.6.6 Safety CCC, BSMI 1.6.7 CE, FCC, CCC, BSMI ARK-5260 User Manual...

  • Page 19: Chapter 2 H/W Installation

    Chapter H/W Installation This chapter introduces external IO and the installation of ARK-5260 hardware.

  • Page 20: Introduction

    2.2.1 Jumper Description You may configure the ARK-5260 to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 21: Jumper List

    2.2.2.2 Watchdog Timer Output Option The ARK-5260 contains a watchdog timer that will reset the CPU in the event the CPU stops processing. This feature means the ARK-5260 will recover from a soft- ware failure or an EMI problem. The JWDT1 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped.

  • Page 22: Connectors

    U S B 3 U S B 4 D IG IT A L IO LP T D C IN P U T Figure 2.1 ARK-5260 front view H D D 1 H D D 2 Figure 2.2 ARK-5260 rear view ARK-5260 User Manual...
  • Page 23 2.3.1.2 Ethernet Connector (LAN) ARK-5260 is equipped two Ethernet controllers that are fully compliant with IEEE 802.3u 10/100/1000 Mbps CSMA/CD standards. LAN1 is equipped with 82567V and LAN2 is equipped with 82583V. The Ethernet port provides a standard RJ-45 jack connector with LED indicators on the front side to show its Active/Link status and Speed status.
  • Page 24 MDI3+ MDI3- 2.3.1.3 Audio Connector ARK-5260 offers stereo audio ports by three phone jack connectors of Line_Out, Line_In, Mic_In. The audio chip is controlled by ALC888, and it’s compliant with Aza- lea standard. Figure 2.5 Audio Connector Table 2.4: Audio Connector Pin Assignments...
  • Page 25 USB_data- USB_data+ 2.3.1.6 VGA Connector The ARK-5260 provides a high resolution VGA interface connected by a D-sub 15- pin connector to support a VGA CRT monitor. It supports display resolution of up to 2048 x 1536. Figure 2.8 VGA Connector...
  • Page 26 Figure 2.9 Parallel Port Connector Table 2.8: Parallel Port Connector Pin Assignments Signal Name Signal Name PIO_STB LPT_AFD# PIO_PD0 LPT_ERR# PIO_PD1 LPT_INIT# PIO_PD2 LPT_SLIN# PIO_PD3 PIO_PD4 PIO_PD5 PIO_PD6 PIO_PD7 LPT_ACK# LPT_BUSY LPT_PE LPT_SLCT ARK-5260 User Manual...
  • Page 27 PS2_KBDAT PS2_MSDAT PS2_KBCLK PS2_MSCLK 2.3.1.9 Power Input Connector ARK-5260 comes with a two pins header as default that carries 12 ~ 24 external power input. Figure 2.11 2-pins header Table 2.10: Power Connector for Pin Header Pin Assignments Signal Name...
  • Page 28 2.3.1.10 Power ON/OFF Button ARK-5260 comes with a Power On/Off button with LED indicators on the front side to show its On status (Green LED) and Off/Suspend status (Orange LED), that support dual function of Soft Power -On/Off (Instant off or Delay 4 Second), and Suspend.

  • Page 29: Installation

    Installation 2.4.1 HDD Installation Unscrew the HDD door screws. Figure 2.14 Unscrew the HDD door screws Pull out the HDD bracket. Figure 2.15 Pull out the HDD bracket ARK-5260 User Manual...
  • Page 30 Assembly the second 2.5" SATA HDD with additional four screws on top of the first HDD. Figure 2.16 Assembly 2.5" SATA HDD and HDD bracket Connect the HDD and SATA cable. Insert the bracket into the HDD housing. Figure 2.17 Insert the bracket into the HDD housing ARK-5260 User Manual...

  • Page 31: Compact Flash Card Installation

    Figure 2.18 Secure the HDD housing with screw Replace the HDD door and secure with screws. 2.4.2 Compact Flash Card Installation Unscrew 2 screws and remove the top cover. Figure 2.19 Unscrew 2 screws and remove the top cover ARK-5260 User Manual...
  • Page 32 Unscrew and remove the top bracket. Figure 2.20 Unscrew and remove the top bracket Install the CF card into the CF socket. Figure 2.21 Install the CF card Replace the top bracket and top cover and secure with screws. ARK-5260 User Manual...

  • Page 33: Memory Installation

    Refer to 2.4.2 step 1~2 to remove the top cover and top bracket. Unscrew two screws from back cover. Figure 2.22 Unscrew four screws from back cover Unscrew 4 screws and remove the right side cover. Figure 2.23 Unscrew 4 screws and remove the right side cover ARK-5260 User Manual...

  • Page 34: Pci / Pciex1 Card Installation

    2.4.4 PCI / PCIex1 Card Installation ARK-5260 provides two PCI slots and one PCIex1 slot for expansion. The procedure of installing the PCI / PCIex1 expansion card into ARK-5260 is instructed below. Refer to 2.4.2 step 1~2 to remove the top cover and top bracket.
  • Page 35 Adjust the depressed rubber height on top bracket, to fit the PCI expansion card. Rotate the rubber to adjust its height Figure 2.26 Adjust the depressed rubber height Replace the top bracket and top cover and secure with screws. ARK-5260 User Manual...
  • Page 36 ARK-5260 User Manual...

  • Page 37: Ami Bios Setup

    Chapter AMI BIOS Setup This chapter introduces how to set BIOS configuration data.

  • Page 38: Introduction

    The Setup program uses a number of menus for making changes and turning special features on or off. This chapter describes the basic navigation of the ARK-5260 setup screens. Figure 3.1 Setup Program Initial Screen AMI's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 39: Entering Setup

    Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. ARK-5260 User Manual...

  • Page 40: Advanced Bios Features Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from the ARK-5260 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 41 While entering setup, the BIOS automatically detects the presence of SATA devices. This displays the status of SATA device auto-detection. IDE Master / Slave While entering setup, the BIOS automatically detects the presence of IDE devices. This displays the status of IDE device auto-detection. AHCI Configuration ARK-5260 User Manual...
  • Page 42 This configures parallel port base addresses. The following options are also available: – Parallel Port Mode This option configures Parallel Port mode. Available options include Normal, Bi-directional, ECP, EPP, ECP & EPP. – Parallel Port IRQ This option configures s Parallel Port base IRQ. ARK-5260 User Manual...
  • Page 43 Auto Flow Control Port 1/2/3/4 This item allows you to ON or OFF auto flow control function. When OFF auto flow control is RS232. – Serial Port 1/2/3/4 Mode This item allows you to select RS232/RS422/RS485 mode. ARK-5260 User Manual...
  • Page 44 ACPI Shut Down Temperature This potion allows user to set the CPU temperature at that the system will auto- matically shut down for preventing CPU from over heat damage. ARK-5260 User Manual...
  • Page 45 This option allows user to set system action when AC power restores after AC power loss. Available options include Power Off, Power On, Last Status. Resume On Ring Disable/Enable RI wake event. Resume On RTC Alarm Disable/Enable RTC wake event. 3.2.2.6 Event Log Configuration Figure 3.10 Event Log Configuration ARK-5260 User Manual...
  • Page 46 USB 2.0 Controller Mode This item allows you to select HiSpeed (480 Mbps) or FullSpeed (12 Mpbs). BIOS EHCI Hand-Off This is a workaround for OSes without EHCI hand-off support. The EHCI owner- ship change should claim by EHCI driver. ARK-5260 User Manual...

  • Page 47: Pci/Pnp Setup

    3.2.3 PCI/PNP Setup Select the PCI/PnP tab from the ARK-5260 setup screen to enter the Plug and Play BIOS Setup screen. Highlighting a Plug and Play BIOS Setup option by using the <Arrow> keys displays a description in the righthand panel. All Plug and Play BIOS Setup options are described in this section.

  • Page 48: Boot Setup Utility

    Available options include Force BIOS, Keep Cur- rent. 3.2.4.4 Bootup Num-Lock Select the Power-on state for Numlock. 3.2.4.5 PS/2 Mouse Support Enable or disable PS/2 interface mouse support. Available options include Auto, Enable, Disable. ARK-5260 User Manual...

  • Page 49: Security Setup

    Security Setup Figure 3.14 Password Configuration Select Security Setup from the ARK-5260 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...

  • Page 50: Advanced Chipset Settings

    Configure DRAM Timing by SPD Allows user to set DRAM operating timing coefficients by SPD or Manual. Initiate Graphic Adapter Allows user to set initial video output device. Available options include IGD, PCI/IGD. Internal Graphics Mode Select ARK-5260 User Manual...
  • Page 51 Allows user to set LVDS panel resolution and signal width. This should match the specification of LVDS panel connected to the CPU card. – Spread Spectrum Enable/Disable spread spectrum. Enable spread spectrum function can have better EMI compatibility but may cause some unexpected peripheral device incompatibility issue. ARK-5260 User Manual...
  • Page 52 SLP_S4# Min. Assertion Width This is for setting delay time between stand by power readiness and ICH SLP_S4# signal triggering. Available options include 1 to 2 seconds, 2 to 3 sec- onds, 3 to 4 seconds, 4 to 5 seconds. ARK-5260 User Manual...

  • Page 53: Exit Options

    Select Discard Changes and Exit from the Exit menu and press <Enter>. The following message appears: Discard Changes and Exit Setup Now? [Ok] [Cancel] Select Ok to discard changes and exit. 3.2.7.3 Discard Changes Select Discard Changes from the Exit menu and press <Enter>. ARK-5260 User Manual...
  • Page 54 3.2.7.4 Load Optimal Defaults The ARK-5260 automatically configures all setup items to optimal settings when you select this option. Optimal Defaults are designed for maximum system performance, but may not work best for all computer applications. In particular, do not use the Opti- mal Defaults if your computer is experiencing system configuration problems.

  • Page 55: Software Installation

    Chapter Software installation This chapter introduces driver installation.

  • Page 56: Driver Installation

    Driver Installation 4.1.1 Chipset driver installation Change folder address to \Driver\00-PCH. And double click to execute infinst_autol.exe. Click "Next" button to the next step. ARK-5260 User Manual...
  • Page 57 Click "Yes" to accept License Agreement. Click "Next" to exit Readme File Information window. ARK-5260 User Manual...

  • Page 58: Graphic Driver Installation

    Select "Yes, I want to restart this computer now." and click "Finish" bottom. The computer will restart automatically. Then the driver installation is completed. 4.1.2 Graphic driver installation Change folder address to \Driver\01-Graphic. And double click to execute setup.exe ARK-5260 User Manual...
  • Page 59 Click "Next" button to skip through welcome window. Click "Yes" to accept License Agreement. ARK-5260 User Manual...
  • Page 60 Click "Next" to exit Readme File Information window. Click "Next" button to continue. ARK-5260 User Manual...

  • Page 61: Audio Driver Installation

    Select "Yes, I want to restart this computer now." and click "Finish" button. The computer will restart automatically. Then the driver installation is completed. 4.1.3 Audio Driver Installation Change folder address to \Driver\02-Audio. And double click to execute WDM_R192.exe. ARK-5260 User Manual...
  • Page 62 Click "Next" button to skip welcome message. Select "Yes, I want to restart this computer now." and click "Finish" button. The computer will restart automatically. Then the driver installation is completed. ARK-5260 User Manual...

  • Page 63: Lan Driver Installation

    4.1.4 LAN Driver Installation Change folder address to \Driver\03-LAN. And double click to execute Auto- run.exe. Select "Install Drivers and Software". ARK-5260 User Manual...
  • Page 64 Click "Next" button to the next step. Select "I accept the terms in the license agreement", and click "Next" button. ARK-5260 User Manual...
  • Page 65 Select Drivers -> Intel(R) PROSet for Windows* Device Manager -> Advanced Networks Services [by default setting]. And click "Next" button to next step. Click "Install" button to start Installation. ARK-5260 User Manual...
  • Page 66 The network driver installation is completed. Click "Finish" button to exit Install Shield. ARK-5260 User Manual...

  • Page 67: Appendix A Programming The Watchdog Timer

    Appendix Programming the Watchdog Timer...

  • Page 68: Watchdog Timer

    Watchdog Timer The ARK-5260's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after a programmed period. This section describes the operation of the watchdog timer and how to program it.

  • Page 69: Programming The Watchdog Timer

    You must first assign the address of the register by writing an address value into address port 2E(hex), then write/read data to/from the assigned register through data port 2F (hex). Unlock W83627DHG-P Select register of watchdog timer Enable watchdog timer function Use the function of the watchdog time Lock W83627DHG-P ARK-5260 User Manual...
  • Page 70 0. [default=0] Bit 4: Read status of watchdog timer, 1 means timer is ""time out""." Write this address to I/O port 2E (hex) to lock the watch- AA (hex) ----- dog timer.2 ARK-5260 User Manual...

  • Page 71: Example Program

    ; Set timeout interval as 10 seconds and start counting al,0f6h dx,al al,10 dx,al ;-------------------------------------------------------------------------------- Dec dx ; lock W83627DHG-P al,0aah dx,al Enable watchdog timer and set 5 minutes as timeout interval ;-------------------------------------------------------------------------------- Mov dx,2eh ; unlock W83627DHG-P Mov al,87h Out dx,al Out dx,al ARK-5260 User Manual...
  • Page 72 ; lock W83627DHG-P al,0aah dx,al Enable watchdog timer to be reset by mouse ;-------------------------------------------------------------------------------- Mov dx,2eh ; unlock W83627DHG-P Mov al,87h Out dx,al Out dx,al ;-------------------------------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer dx,al al,08h dx,al ;-------------------------------------------------------------------------------- ARK-5260 User Manual...
  • Page 73 ; Select registers of watchdog timer dx,al al,08h dx,al ;-------------------------------------------------------------------------------- Dec dx ; Enable the function of watchdog timer al,30h dx,al al,01h dx,al ;-------------------------------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard al,0f7h dx,al al,dx Or al,40h dx,al ARK-5260 User Manual...
  • Page 74 ; Enable the function of watchdog timer al,30h dx,al al,01h dx,al ;-------------------------------------------------------------------------------- Dec dx ; Generate a time-out signal al,0f7h dx,al ;Write 1 to bit 5 of F7 register al,dx Or al,20h dx,al ;-------------------------------------------------------------------------------- Dec dx ; lock W83627DHG-P al,0aah dx,al ARK-5260 User Manual...

  • Page 75: Appendix B Programming The Gpio

    Appendix Programming the GPIO...

  • Page 76: Supported Gpio Register

    Extended Function Index Registers (EFIRs) The EFIRs are write-only registers with port address 2Eh or 4Eh on PC/AT systems. Extended Function Data Registers(EFDRs) The EFDRs are read/write registers with port address 2Fh or 4Fh on PC/AT systems ARK-5260 User Manual...

  • Page 77: Gpio Example Program

    MOV AL,00H ;Set GPIO is normal not inverter OUT DX,AL; MOV DX,4EH MOV AL,F1H OUT DX,AL MOV DX,4FH MOV AL,??H ; Put the output value into AL OUT DX,AL ------------------------------------------------------------ Exit extended function mode | ------------------------------------------------------------ MOV DX,4EH MOV AL,AAH OUT DX, ARK-5260 User Manual...
