Fan Module M07-FAN
EMC Standards GB9254-2008 CLASS A
Safety Standards GB4943-2011
Operating
0 to 50°C
Temperature
Storage
-40 to 70°C
Temperature
Operating Humidity 10%-90% RH (non-condensing)
Long term operation altitude: 3000m at 50℃. The temperature decreases by 1℃ as the altitude
ranging from 3000m to 4000m increases by each 200m.
Altitude
Operation altitude: 4000m max
Storage altitude: 4000m max
MTBF 229,000 hours
59.3 dB at 35℃
Noise
68.4 dB at 50℃
Weight Net weight: 30.2 kg (including chassis and fans)
Dimensions 442 mm x 530 mm x 352.8 mm (cable management brackets excluded), 8U
(W x D x H) 442 mm x 598 mm x 352.8 mm (cable management brackets included), 8U
The weight only includes that of the empty chassis and fans. The whole device's weight is subject to that of
the modules selected.
The RG-S8607E switch is an A-class product and may cause radio disturbance to surroundings. In this case,
users are advised to take proper measures against the disturbance.
Product Appearance
The hardware system of the RG-S8607E switch is composed of the chassis, power system, system modules and cooling
system.
 The power system provides two PoE power supply slots and four system power supply slots, and supports N+M
power supply redundancy. Users are recommended to configure redundancy for the power supplies.
 The RG-S8607E provides two supervisor module slots and five service module slots. The supervisor modules
support 1+1 redundancy. We recommend users to configure redundancy for supervisor modules. Users may select
different service modules as needs.
 The heat dissipation system is composed of fan trays and air filters. Fan trays are on the left side of the chassis, and
air filters are on the right side of the chassis.
Figure 0-6 Appearance of the RG-S8607E Switch
