PowerBox Systems Royal SRS Instruction Manual page 3

FEATURES:
Integral iGyro: triple-axis gyro system with heading function and set-up assistant

Six independent gyro outputs for: 2 x ailerons, 2 x elevators, 2 x rudders

GPS-regulated gyro gain

Special regulatory algorithm for fixed-wing model aircraft

Extremely accurate triple-axis MEMS sensor

Integral Delta and V-tail mixer

Door sequencer: six freely programmable outputs with set-up assistant

PowerBUS: 2 outputs, 16 + 2 channels, compatible with other servo bus systems

Servo-Match function: servo centre, end-points and reverse for all 24 servo outputs

SRS: Serial Receiver System provides the facility to use receivers with serial interface: Spekt-

rum DSM2 and DSMX, Multiplex M-Link, Futaba S-Bus, HoTT and Jeti R-SAT2
Unrestricted channel assignment for all 24 PowerBox outputs

Graphic LCD screen with 128 x 64 pixels

Extremely user-friendly menu-based programming using the SensorSwitch

Facility to adjust settings using Bluetooth and Smartphone app

Up to 18 channels - depending on the radio control system in use

Signal amplification and interference suppression for all 24 outputs

Flight recorder, recording of lost frames, fail-safe events and all battery data

Variable frame rate, range 12 ms – 21 ms

Two 16-bit processors for fast, high-resolution signal processing

2 x double-regulated output voltages for receivers and servos

2 regulated voltage ranges with independent selection facility, 5.9 V or 7.4 V

Facility to connect downlink bus systems from Futaba, Jeti, Spektrum, HoTT and Multiplex MSB

Directly transmits battery data, receiver data and GPS data to the transmitter

Separate voltage and capacity display for each battery

Minimum value memory alerts the user to voltage collapses

Large-area heat-sinks for high regulator performance

Regulator monitoring, regulator error indicator

Support for three battery types: LiPo, NiMH / NiCd, LiFePo

Suppression of any servo feedback currents which may occur
