  • Page 1 Instruction Manual GEMini ii...
  • Page 2 Dear customer, We are delighted that you have decided to purchase the PowerBox Gemini II po- wer supply from our range. We hope you have many hours of pleasure and great success with your Power- Box Gemini II. PRODUCT DESCRIPTION The Gemini II is the logical development of the PowerBox Gemini, which we have produced un-changed since 2005.

  • Page 3: Table Of Contents

    Features: - Double-regulated output voltage - Electronic On / Off switch, using either a magnetic trigger or the SensorSwitch - On and Off switching signalled by visual and audible indicators - Regulated output voltage of 5.9 V or 7.4 V - LED voltage indicator for each battery separately - Supports three battery types: LiPo/LiIon, NiMH/NiCd, LiFePo - Suppression of any servo feedback currents which might occur...

  • Page 4: Lay-Out And Connections

    1. LAY-OUT AND CONNECTIONS Sockets for patch-leads to receiver Battery inputs High-perfor- Buzzer mance heat-sink output Switching zone for magnetic trigger SensorSwitch socket PowerBox-Systems − World Leaders in RC Power Supply Systems...

  • Page 5: Connecting The Batteries And The Sensorswitch

    CAUTION: connecting the batteries with reversed polarity will instantly destroy the two regulators in the Gemini II. If this should happen, the regulator monitor causes the two LEDs to flash alternately red and green to indicate the fault.

  • Page 6: B) Using The Magnetic Trigger

    This setting can only be changed using the SensorSwitch. This is the procedure for setting the various battery types: - Connect both batteries, and switch on the Gemini II. - Hold the Set button pressed in, and observe the LEDs.

  • Page 7: Setting The Output Voltage

    5. SETTING THE OUTPUT VOLTAGE It is possible to set your PowerBox Gemini II to either of two different output voltages. The default stabilised voltage (as delivered) is 5.9 Volt. The performance of your PowerBox Gemini II is around 30% higher when opera- ting at 7.4 Volt due to the reduced dissipated power.
  • Page 8 CAUTION: before you set the unit to 7.4 V it is essential to check that all consu- mer units connected to the system - all servos, receiver, gyro, etc. - are expressly approved for use with the higher voltage. Information on this matter can be found in the instructions provided by the equipment manufacturers.

  • Page 9: Specification

    CE approval: 2004/108/EG WEEE Reg. No. DE 639 766 11 7. SET CONTENTS - PowerBox Gemini II - SensorSwitch - magnetic trigger with PowerBox keyring - 2 patch-leads, 210 mm - Double-sided self-adhesive pad - Operating instructions in German and English...

  • Page 10: Dimensions

    8. DIMENSIONS PowerBox-Systems − World Leaders in RC Power Supply Systems...
  • Page 11 9. SERVICE NOTE We are anxious to offer good service to our customers, and to this end we have set up a Support Forum which deals with all queries concerning our products. This relieves us of a great deal of work, as it eliminates the need to answer frequently asked questions time and again.

  • Page 12: Guarantee Conditions

    10. GUARANTEE CONDITIONS At PowerBox-Systems we insist on the highest possible quality standards in the development and manufacture of our products. They are guaranteed “Made in Germany”! That is why we are able to grant a 24 month guarantee on our PowerBox Gemini ll from the initial date of purchase.

  • Page 13: Liability Exclusion

    11. LIABILITY EXCLUSION We are not in a position to ensure that you observe our instructions regarding installation of the PowerBox Gemini ll, fulfil the recommended conditions when using the unit, or maintain the entire radio control system competently. For this reason we deny liability for loss, damage or costs which arise due to the use or operation of the PowerBox Gemini ll, or which are connected with such use in any way.
  • Page 14 12/2020 PowerBox-Systems GmbH Ludwig-Auer-Straße 5 D-86609 Donauwoerth Germany +49-906-99 99 9-200 +49-906-99 99 9-209 www.powerbox-systems.com...
