PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
#8 x 16mm M4 x 16mm Flat M4 x 22mm M6 x 12mm
Screw Head Screw Screw Screw
(111)–4 (101)–10 (107)–10 (108)–8
M8 x 15mm M8 x 20mm M8 x 25mm M10 x 20mm
Screw (96)–2 Screw (102)–8 Screw (105)–6 Screw (110)–8
M8 x 86mm Screw
(109)–2
