2. With the help of a second person, place some of
the packing materials (not shown) under the right
side of the Frame (1). Have the second person
hold the Frame to prevent it from tipping
while you complete this step.
Identify the Right and Left Stabilizers (8, 9) and
orient them as shown.
Attach the Right Stabilizer (8) to the Frame (1)
with four M10 x 20mm Screws (110); start all
the Screws, and then tighten them.
Then, remove the packing materials from under
the right side of the Frame (1).
Attach the Left Stabilizer (9) in the same way.
3. Identify the Right and Left Pedal Bases (2, 3)
and the Right and Left Pedals (22, 23), and
orient them as shown.
Attach the Right Pedal (22) to the Right Pedal
Base (2) with four M6 x 12mm Screws (108);
start all the Screws, and then tighten them.
Attach the Left Pedal (23) to the Left Pedal
Base (3) in the same way.
2
9
3
23
10
110
110
1
110
8
3
22
2
108
108
