Model No. PFEL01420-INT.0
Serial No.
Write the serial number in the space
above for reference.
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness, Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Serial
Number
Decal
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form PRO-HIT H14

Summary of Contents for Pro-Form PRO-HIT H14

  • Page 1 USER’S MANUAL Model No. PFEL01420-INT.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on the trainer before using the trainer. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM ® reading this manual, please see the front cover of this PRO HIIT H14 trainer. The PRO HIIT H14 trainer manual. To help us assist you, note the product model provides an impressive selection of features designed number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you fi...
  • Page 7 2. Identify the Right and Left Stabilizers (8, 9) and orient them as shown. Have a second person hold the Frame (1) and tip it to the left. IMPORTANT: Be careful not to damage the Shields (50, 51). Attach the Right Stabilizer (8) to the Frame (1) with four M10 x 20mm Screws (110);...
  • Page 8 4. Attach the Right Pedal Base (2) to the Right Pedal Leg (24) with four M8 x 20mm Screws (102); start all the Screws, and then tighten them. Attach the Left Pedal Base (3) to the Left Pedal Leg (25) in the same way. 5.
  • Page 9 6. See the upper drawing. With the help of a second person, orient the Console (5), the Console Cover (7), and the Console Bracket (4) as shown. Then, route the wires (A) on the Console through the Console Cover and the Console Bracket.
  • Page 10 8. Identify the Right and Left Handlebars (10, 11). Make sure that the Pedals (22, 23) are level. Attach the Right Handlebar (10) to the Right Handlebar Arm (15) with three M8 x 25mm Screws (105); start all the Screws, and then tighten them.
  • Page 11 10. Attach the Front Cover (52) to the Left and Right Shields (50, 51) with six M4 x 16mm Flat Head Screws (101); start all the Flat Head Screws, and then tighten them. 50, 51 11. Plug the Power Adapter (118) into the receptacle on the front of the trainer.

  • Page 12: How To Use The Trainer

    HOW TO USE THE TRAINER HOW TO PLUG IN THE POWER ADAPTER HOW TO MOVE THE TRAINER IMPORTANT: If the trainer has been exposed to Due to the size and weight of the trainer, moving cold temperatures, allow it to warm to room tem- it requires two persons.
  • Page 13 HOW TO EXERCISE ON THE TRAINER HOW TO LEVEL THE TRAINER To mount the trainer, hold the handlebars (D) or the If the trainer pulse grips (E) and step onto the pedal (F) that is in the rocks slightly on lower position.

  • Page 14: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals with the touch The advanced console offers an array of features of a button. designed to make your workouts more effective and enjoyable.
  • Page 15 HOW TO TURN ON THE CONSOLE HOW TO USE THE TOUCH SCREEN The included power adapter must be used to oper- The console features a tablet with a full-color touch ate the trainer. See HOW TO PLUG IN THE POWER screen.
  • Page 16 HOW TO SET UP THE CONSOLE To use the manual mode, see this page. To use a featured workout or an onboard workout, see Before you use the trainer for the first time, set up the page 18. To create a draw-your-own-map work- console.
  • Page 17 4. Follow your progress. rate monitor with your palms resting against the contacts. Avoid moving your hands or gripping The console offers several display modes. The the contacts tightly. display mode that you select will determine which workout information is shown. When your pulse is detected, your heart rate will be shown.
  • Page 18 HOW TO USE A FEATURED WORKOUT OR AN To draw your own map for a workout, see HOW TO ONBOARD WORKOUT CREATE A DRAW-YOUR-OWN-MAP WORKOUT on page 20. 1. Touch the screen or press any button on the console to turn on the console. When you select a workout, the screen will show an overview of the workout that includes details See HOW TO TURN ON THE CONSOLE on...
  • Page 19 If the resistance level is too high or too low, you When the workout ends, a workout summary will can manually override the setting by pressing the appear on the screen. If desired, you can select Resistance buttons. If you press a Resistance options such as adding the workout to your sched- button, you can then manually control the resis- ule (see HOW TO USE AN IFIT WORKOUT on...
  • Page 20 HOW TO CREATE A DRAW-YOUR-OWN-MAP If you make a mistake, touch Undo in the map WORKOUT options. 1. Touch the screen or press any button on the The screen will display the elevation and distance console to turn on the console. statistics for your workout.
  • Page 21 HOW TO USE AN IFIT WORKOUT 4. Select an iFit workout from the home screen or the workout library. To use an iFit workout, you must be logged into your iFit account (see step 3 below) and the console Touch the buttons at the bottom of the screen to must be connected to a wireless network (see HOW select either the home screen (Home button) or the TO CONNECT TO A WIRELESS NETWORK on...
  • Page 22 6. Create a list of favorite iFit workouts if desired. 9. Measure your heart rate if desired. To mark an iFit workout as a favorite, simply view See step 5 on page 17. the overview or workout summary of the desired iFit workout and touch the favorites button (heart 10.
  • Page 23 HOW TO CHANGE CONSOLE SETTINGS 3. Customize the unit of measurement and other settings. IMPORTANT: Some of the settings and features described may not be enabled. Occasionally, a To customize the unit of measurement, the time firmware update may cause your console to function zone, or other settings, touch Equipment Info or slightly differently.
  • Page 24 HOW TO CONNECT TO A WIRELESS NETWORK Note: You must have your own wireless network and an 802.11b/g/n router with SSID broadcast To use iFit workouts and to use several other features enabled (hidden networks are not supported). of the console, the console must be connected to a wireless network.
  • Page 25 HOW TO USE THE SOUND SYSTEM Note: The console can save 8 devices in its memory. If you have previously paired your device Connect with an Audio Cable to the console, you can simply press the Bluetooth To play music or audio books through the console Audio button to connect your device to the console.
  • Page 26 THE OPTIONAL HEART RATE MONITOR during your workouts. The optional heart rate monitor will enable you to continuously monitor your heart rate Whether your while you exercise, helping you to reach your personal goal is to fitness goals. To purchase an optional heart rate burn fat or to monitor, please see the front cover of this manual.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE If the console does not boot up properly, or if the con- Regular maintenance is important for optimal sole freezes and does not performance and to reduce wear. Inspect and respond, reset the console properly tighten all parts each time the trainer is to the factory default set- used.
  • Page 28 HOW TO ADJUST THE REED SWITCH Next, turn the Large Pulley (21) until a Pulley Magnet (104) is aligned with the Reed Switch (116). Then, If the console does not display correct feedback, the slightly loosen the M4 x 19mm Screw (113), slide the reed switch should be adjusted.
  • Page 29 HOW TO ADJUST THE DRIVE BELT Stand on the trainer and pedal for a few moments. If the pedals still slip, step off the trainer and locate If the pedals slip while you are pedaling, even while the upper Adjustment Screw (B). Tighten the upper the resistance is adjusted to the highest level, the drive Adjustment Screw two turns;...

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 31 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 32: Part List

    PART LIST Model No. PFEL01420-INT.0 R0321A Key No. Qty. Description Key No. Qty. Description Frame Right Shield Right Pedal Base Front Cover Left Pedal Base Rear Cover Console Bracket Accessory Tray Base Console Stabilizer Cap Snap Ring Foot Console Cover Wheel Right Stabilizer Right Wheel Cover...
  • Page 33 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Flat Head Screw M10 Screw M8 x 20mm Screw M4 x 19mm Screw Cap Screw M4 x 12mm Screw Pulley Magnet Main Wire M8 x 25mm Screw Reed Switch/Wire M4 x 16mm Screw Pulse Wire M4 x 22mm Screw...

  • Page 34: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEL01420-INT.0 R0321A...
  • Page 35 EXPLODED DRAWING B Model No. PFEL01420-INT.0 R0321A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
