FAS-204 BEARING MEASURING/TRANSFERING MODULE
FUNCTION OF THE MODULE:
This fourth module is complementary to
previous one. Is in this module where the
height is measured to differentiate between
the two sizes of bearings.
Figure 37: Manipulators of the fourth module.
User Manual for FAS200
FLEXIBLE ASSEMBLY SYSTEM FAS200
Figure 36: FAS204 Bearing
Measuring/Transfering Module.
- 31 -
