TROUB-200 FAULT SIMULATION SYSTEM
Most of the modules incorporate a Fault Simulation System TROUB-200 fitted
to the side of each module or in the electrical panel, depending of the
configuration.
Figure 18: TROUB-200 in the
electrical panel.
The system consists of a lockable box containing 16 switches which, when
operated, cause a fault in the module.
In the Appendix A, there are more details about this Fault Simulation System,
with a series of tables, per module, where the error symptom, suspicious
components and the final faulty component can be found.
User Manual for FAS200
FLEXIBLE ASSEMBLY SYSTEM FAS200
Figure 19: TROUB-200 in a side of
module.
