Signal on alarm
Linearization
Galvanic isolation
16
Switch output
Function
Open collector switching output
Switching behavior
Binary (conductive or non-conductive), switches when the programmable switch
point is reached
Failure mode
non-conductive
Electrical connection
U = 10.4 to 35 V
values
Internal resistance
R
The voltage drop at this internal resistance has to be taken into account on
planning the configuration. For example, the resulting voltage at a connected
relay must be sufficient to switch the relay.
Insulation voltage
floating, Insulation voltage 1 350 V
Switch point
freely programmable, separately for switch-on and switch-off point
Switching delay
freely programmable from 0 to 100 sec. , separately for switch-on and switch-off
point
Number of switching cycles corresponds to the measuring cycle
Signal source
• Level linearized
device variables
• Distance
• Terminal voltage
• Electronic temperature
• Relative echo amplitude
• Interface linearized
• Interface distance
• Upper interface thickness
• Relative interface amplitude
• Diagnostic values, Advanced diagnostics
Number of switching cycles unlimited
1)
only if an interface measurement is active
Depending on the interface, failure information is displayed as follows:
• Current output (for HART devices)
– Failsafe mode selectable (in accordance with NAMUR Recommendation NE 43):
Minimum alarm: 3.6 mA
Maximum alarm (= factory setting): 22 mA
– Failsafe mode with user-selectable value: 3.59 to 22.5 mA
• Local display
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
• Operating tool via digital communication (HART, PROFIBUS PA, FOUNDATION Fieldbus) or
service interface (CDI)
– Status signal (in accordance with NAMUR Recommendation NE 107)
– Plain text display
The linearization function of the device allows the conversion of the measured value into any unit of
length or volume. Linearization tables for calculating the volume in cylindrical tanks are pre-
programmed. Other tables of up to 32 value pairs can be entered manually or semi-automatically.
All circuits for the outputs are galvanically isolated from each other.
, I = 0 to 40 mA
DC
< 880 Ω
I
1)
1)
1)
1)
Levelflex FMP51, FMP52, FMP54
to power supply aund 500 V
DC
Endress+Hauser
to ground
AC
