Levelflex FMP51, FMP52, FMP54

AD2000

NACE MR 0175 / ISO 15156

NACE MR 0103

ASME B31.1 and B31.3

Pressure Equipment
Directive

Steam boiler approval

Marine certificate

Telecommunications

CRN-Zulassung

Endress+Hauser
• For FMP51/FMP54:
The wetted material 316L (1.4435/1.4404) corresponds to AD2000 - W2/W10.
• For FMP52/FMP55:
The pressure retaining material 316L (1.4435/1.4404) corresponds to AD2000 - W2/W10.
• Declaration of conformity: see product structure, feature 580, option JF.
For FMP51, FMP54, FMP55:
• The wetted, metallic materials comply with the requirements of NACE MR 0175 / ISO 15156.
• Declaration of conformity: see product structure, feature 580, option JB.
For FMP51, FMP54, FMP55:
• The wetted, metallic materials comply with the requirements of NACE MR 0103.
• The certificate of compliance is based on NACE MR 0175.
The hardness and the intercrystalline corrision have been tested, as well as the heat treatment
(solution annealed) has been carried out. The used materials comply therefore with the
requirements of NACE MR 0103.
• Declaration of conformity: see product structure, feature 580, option JE.
• The dimensions, materials of construction, pressure / temperature ratings and identification
markings of the device comply with the requirements of AMSE B31.1 and ASME B31.3
• Declaration of conformity: see product structure, feature 580, option KV.
Conformity assessment was carried out as per Module A, the proof of statical stability and endurance
strength as per EN 13445 and AD2000.
The FMP54 corresponds to the 97/23/EC Directive (Pressure Equipment Directive). It is a
pressure accessory with a volume < 0.1 l, corresponding to Category I.
The FMP54 is not suitable for use with unstable gases at nominal pressures above
200 bar (2 900 psi).
The FMP54 is approved as a limiting device for high water (HW) and low water (LW) for liquids in
containers which are subject to the requirements of EN12952-11 and EN12953-9 (certified by TÜV
Nord).
Product structure: Feature 590 "Additional Approval", option LX "Steam boiler approval".
For details refer to Safety Instructions SD00349F and Planning Recommendations SD01071F.
Device with steam boiler approval always have a SIL approval as well.
• GL (Germanischer Lloyd)
• ABS (American Bureau of Shipping)
• LR (Lloyd' s Register)
• DNV (Det Norske Veritas)
• BV (Bureau Veritas)
Only in connection with HART or PROFIBUS PA.
Complies with part 15 of the FCC rules for an unintentional radiator. All probes meet the
requirements for a Class A digital device.
In addition, all probes in metallic tanks as well as the coax probe meet the requirements for a Class B
digital device.
Some device versions have a CRN approval. Devices are CRN approved if the folowing two conditions
are met:
• The device has a CSA approval (Product structure: Feature 010 "Approval")
• The device has a CRN approved process connection according to the following table.
Feature 010 of the product structure
AAJ
ABJ
Approval
2" 300/600lbs RF, 316/316L flange ANSI B16.5
3" 300/600lbs RF, 316/316L flange ANSI B16.5
