Figure 2.1. DE2 Development Board Components & Interfaces
DE2 board provides users many features to enable various multimedia project
development. Component selection was made according to the most popular
design in volume production multimedia products such as DVD, VCD, and MP3
players. The DE2 platform allows users to quickly understand all the insight tricks
to design real multimedia projects for industry.
Altera Cyclone II 2C35 FPGA with 35000 LEs
Altera Serial Configuration deivices (EPCS16) for Cyclone II 2C35
USB Blaster built in on board for programming and user API controlling
JTAG Mode and AS Mode are supported
8Mbyte (1M x 4 x 16) SDRAM
1Mbyte Flash Memory (upgradeable to 4Mbyte)
SD Card Socket
4 Push-button switches
18 DPDT switches
9 Green User LEDs
