Altera DE2 Board Getting Started Manual page 25

Signal Name FPGA Pin No.
HEX0[0] PIN_AF10
HEX0[1] PIN_AB12
HEX0[2] PIN_AC12
HEX0[3] PIN_AD11
HEX0[4] PIN_AE11
HEX0[5] PIN_V14
HEX0[6] PIN_V13
HEX1[0] PIN_V20
HEX1[1] PIN_V21
HEX1[2] PIN_W21
HEX1[3] PIN_Y22
HEX1[4] PIN_AA24
HEX1[5] PIN_AA23
HEX1[6] PIN_AB24
HEX2[0] PIN_AB23
HEX2[1] PIN_V22
HEX2[2] PIN_AC25
HEX2[3] PIN_AC26
HEX2[4] PIN_AB26
HEX2[5] PIN_AB25
HEX2[6] PIN_Y24
HEX3[0] PIN_Y23
HEX3[1] PIN_AA25
HEX3[2] PIN_AA26
HEX3[3] PIN_Y26
HEX3[4] PIN_Y25
HEX3[5] PIN_U22
HEX3[6] PIN_W24
HEX4[0] PIN_U9
HEX4[1] PIN_U1
HEX4[2] PIN_U2
HEX4[3] PIN_T4
HEX4[4] PIN_R7
HEX4[5] PIN_R6
HEX4[6] PIN_T3
HEX5[0] PIN_T2
HEX5[1] PIN_P6
22
Using the System
Description
Seven Segment Digital 0[0]
Seven Segment Digital 0[1]
Seven Segment Digital 0[2]
Seven Segment Digital 0[3]
Seven Segment Digital 0[4]
Seven Segment Digital 0[5]
Seven Segment Digital 0[6]
Seven Segment Digital 1[0]
Seven Segment Digital 1[1]
Seven Segment Digital 1[2]
Seven Segment Digital 1[3]
Seven Segment Digital 1[4]
Seven Segment Digital 1[5]
Seven Segment Digital 1[6]
Seven Segment Digital 2[0]
Seven Segment Digital 2[1]
Seven Segment Digital 2[2]
Seven Segment Digital 2[3]
Seven Segment Digital 2[4]
Seven Segment Digital 2[5]
Seven Segment Digital 2[6]
Seven Segment Digital 3[0]
Seven Segment Digital 3[1]
Seven Segment Digital 3[2]
Seven Segment Digital 3[3]
Seven Segment Digital 3[4]
Seven Segment Digital 3[5]
Seven Segment Digital 3[6]
Seven Segment Digital 4[0]
Seven Segment Digital 4[1]
Seven Segment Digital 4[2]
Seven Segment Digital 4[3]
Seven Segment Digital 4[4]
Seven Segment Digital 4[5]
Seven Segment Digital 4[6]
Seven Segment Digital 5[0]
Seven Segment Digital 5[1]
