KMT12/KMT18

11. SPECIFICATIONS

KMT12
Acoustics
Speakers power
700 w (EAS)
handling
Maximum power 1200 w 1
Impedance 8Ω
Frequency range 40Hz - 150 Hz +/- 3dB (preset dependent)
SPL 1W/1mt 99 dB
2
Maximum SPL 128 dB continuous - 134 dB peak
Coverage
Omni
Crossover
Type DSP controlled
Frequency 150 Hz maximum (preset dependent)
Transducers
1 x 12" Neodymium speakers with 3"
voice coil
Audio Input
Analog 2 male + 2 female 3-pin balanced XLR
Connectors
Digital 1 male + 1 female 3-pin XLR
Connectors
Audio powered Output
Connector Female Speakon
Pin1+= CH1+ Pin1= CH1- Pin2+= N.C.
Wiring
Pin2= N.C.
Remote control Input
Notes for data
1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
3. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce
into the nominal load impedance.
New materials and design are introduced into existing products without previous notice. Present systems may differ in
some respects from those presented in this brochure.
24
Connectors 1 male + 1 female XLR parallel
1 USB B Jack serial converter
Power Input
Connectors 2 x PowerCon IN/OUT
Amplifiers
Type 1 modules class D - DSP controlled
Subwoofer power 1000 Watt @8Ω
3
Speaker power
1000 Watt @8Ω
3
output
Dynamic limiter, over current, over temp,
Protection
short circuits
AC power
Operating range 100 - 120 Vac 60Hz / 210 - 240 Vac 50Hz
(Auto Switch)
I. nom 5.5 A / 115 Vac - 2.9 A / 230 Vac
Minimum
95 Vac - 195 Vac
operation voltage
Maximum
125 Vac - 205 Vac
operation voltage
Max continuos Default 6A(>10 sec) - 12A (<1 sec)
and Selectable 10A(>10 sec) - 20A (<1sec)
burst current
Physical
32.5 x 33.5 x 43.5 cm
Dimensions
(12.91" x 13.19" x 17.13")
Weight ??
Speakers power
handling
Maximum power
Impedance
Frequency range 30Hz - 150 Hz +/- 3dB (preset dependent)
SPL 1W/1mt
Maximum SPL
Type
Frequency 150 Hz maximum (preset dependent)
1 x 12" Neodymium speakers with 3"
Analog 2 male + 2 female 3-pin balanced XLR
Connectors
Digital
Connectors
Connector
Pin1+= CH1+ Pin1= CH1- Pin2+= N.C.
Wiring
Notes for data
1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
3. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce
into the nominal load impedance.
New materials and design are introduced into existing products without previous notice. Present systems may differ in
some respects from those presented in this brochure.
REV. A REV. A
KMT18
Acoustics
800 w (EAS)
1400 w 1
Connectors
8Ω
99 dB
2
Connectors
130 dB continuous - 136 dB peak
Coverage
Omni
Subwoofer power
Crossover
Speaker power
output
DSP controlled
Protection
Transducers
Operating range
voice coil
I. nom
Audio Input
Minimum
operation voltage
Maximum
1 male + 1 female 3-pin XLR
operation voltage
Audio powered Output
Max continuos
burst current
Female Speakon
Pin2= N.C.
Dimensions
Weight
KMT12/KMT18
Remote control Input
1 male + 1 female XLR parallel
1 USB B Jack serial converter
Power Input
2 x PowerCon IN/OUT
Amplifiers
Type 1 modules class D - DSP controlled
1000 Watt 3 @8Ω
1000 Watt @8Ω
3
Dynamic limiter, over current, over temp,
short circuits
AC power
100 - 120 Vac 60Hz / 210 - 240 Vac 50Hz
(Auto Switch)
5.5 A / 115 Vac - 2.9 A / 230 Vac
95 Vac - 195 Vac
125 Vac - 205 Vac
Default 6A(>10 sec) - 12A (<1 sec)
and Selectable 10A(>10 sec) - 20A (<1sec)
Physical
46.5 x 47.5 x 61 cm
(18.31"x 18.70" x 24.02")
28 Kg (61.73 lbs)
