Technical Specifications - K-array Truffle Series User Manual

Technical Specifications

Type
Rated Power
Frequency Response
1
Maximum SPL
2
Coverage
Transducers
Colors
Finishes
Material
Dimensions
(WxHxD)
Weight
IP Rating
Impedance
With dedicated preset
1
Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 1 m.
2
Truffle-KTR24
Passive subwoofer
60 W
45 Hz – 150 Hz (-6 dB)
112 dB (peak)
Omni
4" woofer + passive radiator
122 x 117 x 199 mm
(4.8 x 4.6 x 7.8 in)
1,5 kg (3.31 lb)
4 Ω
Truffle-KTR25
Passive subwoofer
80 W
45 Hz – 150 Hz (-6 dB)
115 dB (peak)
Omni
5.25" woofer + passive radiator
Black
Powder Matte
Aluminum
152 x 147 x 258 mm
(6.0 x 5.8 x 10.2 in)
2,5 kg (5.51 lb)
IP54
4 Ω
Truffle
User Guide
Truffle-KTR26
Passive subwoofer
100 W
45 Hz – 150 Hz (-6 dB)
120 dB (peak)
Omni
6.5" woofer + passive radiator
182 x 176 x 341 mm
(7.1 x 6.9 x 13.4 in)
3,5 kg (7.72 lb)
2 Ω
11
