KMT12/KMT18

9. K-Framework

9.1 System requirements

SYSTEM REQUIREMENTS:
Operating System: Windows Xp / Vista / 7
CPU: Intel Pentium Dual Core
Memory: 2 Gb
REQUIRED COMPONENTS:
.NET Framework 4
http://www.microsoft.com/downloads/en/details.aspx?FamilyID=0a391abd-25c1-4fc0-919f-b21f31ab88b7
Microsoft Visual C++ 2010 Redistributable Package (x86)
http://www.microsoft.com/download/en/details.aspx?id=5555
Microsoft Visual C++ 2010 Redistributable Package (x64)
http://www.microsoft.com/download/en/details.aspx?id=14632

9.2 Installation and set up

To download your free K-Framework license, please go to the "Software Download" page of the Blueline website (http://
www.kblueline.com).
Once the .zip file is decompressed, it will show a folder containing the file "K-Framework.setup".
-Users of Windows Vista and 7 can install the software by simply opening the K-Framework.setup file.
-Users of Windows XP are required to follow the following simple procedure to install the necessary drivers, once the
K-Framework software has been installed:
1)
Recall the "Manage" window from "Start Menu/My Computer".
2)
Select "Device Manager" from the menu on the left and expand the "USB controllers" sub-menu.
16
3)
Right click on the upper "K-Array_Dsp01" object and select "Driver Update" to launch the "Hardware Update
Wizard"
4)
When asked to allow the online search select the "Not now" option and click on "Next".
5)
When asked for the drivers' location, select the "Install from a list or specific location" option.
6)
In the search and installation options window, select the "Search for the best driver in this location" option and
check the "Include this location in the search" checkbox, then browse for the drivers' containing folder. The path
should read:
C:\ProgramFiles\K-array\K-framework\drivers_rev02
Once you have inserted the right search path, click "Next".
7)
When warned about a failed "Windows Logo" test, please ignore the content of the warning and click "Next".
8)
The first part of driver installation is now complete, and the "unknown" K-Array_Dsp01 port has changed its
name to a univocal "K-Array_Dsp01 A". Click on "Finish" and repeat exactly the same procedure for the still unknown
port.
9)
Now you can see that inside the Device Manager Window both devices now have a univocal name and the alert
symbol is no longer associated with them. Now you are 100% ready to get started!
REV. A REV. A
5 6
KMT12/KMT18
17
